LG 55LA9650 User Manual

ENGLISH
8
TABLE OF CONTENTS
2 IMPORTANT SAFETY INSTRUCTIONS
6 Viewing 3D Imaging
7 LICENSES
7 OPEN SOURCE SOFTWARE NOTICE
8 TABLE OF CONTENTS
9 INSTALLATION PROCEDURE
9 ASSEMBLING AND PREPARING
9 Unpacking
11 Optional Extras
12 Parts and Buttons
13 Lifting and Moving the TV
14 Setting up the TV
14 - Attaching the Stand
15 - Mounting on a Table
16 - Tidying cables
16 - Mounting on a Wall
18 MAKING CONNECTIONS
18 Connecting to an Antenna or Cable
19 Connecting to a HD receiver, DVD Player or
VCR
19 - HDMI Connection
20 - DVI to HDMI Connection
21 - Connecting to a Mobile Phone
22 - Component Connection
23 - Composite Connection
24 Connecting a PC
24 - HDMI Connection or DVI to HDMI
Connection
26 Connecting to an Audio System
26 - Digital Optical Audio Connection
27 Connecting Headphones
28 Connecting a USB Device
29 MAGIC REMOTE CONTROL
FUNCTIONS
30 Registering Magic Remote Control
30 How to use Magic Remote Control
30 Precautions to Take when Using the Magic
Remote Control
31 WATCHING TV
31 Turning the TV on for the First Time
32 USING THE USER GUIDE
33 SPECIFICATIONS
36 EXTERNAL CONTROL DEVICE SETUP
37 MAINTENANCE
37 Cleaning Your TV
37 - Screen, Frame, Cabinet, and Stand
37 - Power Cord
37 TROUBLESHOOTING
TABLE OF CONTENTS
y
Image shown may differ from your TV.
y
Your TV’s OSD (On Screen Display) may
differ slightly from that shown in this
manual.
y
The available menus and options may
differ from the input source or product
model that you are using.
y
New features may be added to this TV in
the future.
NOTE

LG 55LA9650 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	54.6 \
Display brightness	- cd/m²
Native aspect ratio	16:9
Supported video modes	720p, 1080i, 1080p
Screen format adjustments	4:3, 14:9, 16:9
Supported graphics resolutions	3840 x 2160
Motion interpolation technology	-
3D	Yes
3D type	Passive
Built-in camera	No
Bundled software	Windows 8 Certified
3D glasses quantity	4
Storage temperature (T-T)	-20 - 60 °C
Supported 3D technologies	LG Cinema 3D
Storage relative humidity (H-H)	70 - 85 %
Operating relative humidity (H-H)	70 - 80 %
Smart modes	Game, Movie, Standard, Vivid
Operating system version	Home Dashboard 3.0
Sound modes	Game, Movie, Music, Sports, Standard
Audio decoders	Dolby Digital
RMS rated power	34 W
Number of speakers	2
Equalizer bands quantity	6
RF ports quantity	1
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio formats supported	AAC, AC3, EAC3, HAAC, MP3, PCM
Image formats supported	JPEG XR
Video formats supported	DIVX HD, MPEG
Product color	Silver
Compatible products	AN-MR400 AN-VC500 AN-VC400 AG-F315
Panel mounting interface	400 x 400 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Operating temperature (T-T)	0 - 40 °C
Remote control type	Magic
Package depth	178 mm
Package width	1295 mm
Package height	840 mm
Package weight	31752 g

Weight and Dimensions

Depth (with stand)	261 mm
Height (with stand)	790 mm
Weight (with stand)	24600 g
Depth (without stand)	- mm
Width (without stand)	1220 mm
Height (without stand)	740 mm
Weight (without stand)	26100 g
