LG 55LB5610 User Manual

A. Video error
Tuning fail, Picture broken/ Freezing
Y
N
☞ A5
Check RF Signal level
Check
S/W Version
S/W Upgrade
Y
N
Y
Check RF signal cable (DVB satellite signal or not)
Check whether other equipments have problem or not.
(By connecting RF Cable at other equipment)
→ Set-Top-Box, Different maker TV etc
Y
Change satellite setting
(match with installed ANT)
N
Y
N
☞ A6
Standard Repair Process
Established
date
Revised date
4/14
LCD TV
Error
symptom
2012. 01 .14
Check satellite setting.
- Check LNB frequency.
- Check satellite
- Check Satellite connection
(DiSEqC, motor, etc…)
Contact with signal
distributor
or broadcaster
(Cable or Air)
N
Check
Tuner soldering
Replace
Main B/D
Normal
End
Normal
Normal
Setting
SVC
Bulletin
Normal
Signal
End
End
Copyright © 2013 LG Electronics. Inc. All rights reserved.
Only for training and service purposes
LGE Internal Use Only

LG 55LB5610 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	55 \
Display brightness	- cd/m²
Native aspect ratio	16:9
Native refresh rate	50 Hz
LED backlighting type	-
Display diagonal (metric)	139 cm
Motion interpolation technology	MCI (Motion Clarity Index) 100
Tuner type	Analog & digital
Digital signal format system	DVB-T
Audio system	Virtual Surround
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	- W

Weight and Dimensions

Depth (with stand)	255 mm
Height (with stand)	772 mm
Weight (with stand)	18400 g
Depth (without stand)	57 mm
Width (without stand)	1243 mm
Height (without stand)	725 mm
Weight (without stand)	18000 g
