LG 55LB5610 User Manual

Contents of LCD TV Standard Repair Process Detail Technical Manual
No. Error symptom Content Page Remarks
21
B. Power error_No power
Check front display LED A11
22 Check power input Voltage & ST-BY 3.5V A12
23 Checking method when power is ON A13
24 POWER BOARD voltage measuring method A4
25
26
B. Power error_Off when on, off while
viewing
POWER OFF MODE checking method A14
28
C. Audio error_No audio/Normal video
Checking method in menu when there is no
audio
A15
29
Voltage and speaker checking method when
there is no audio
A16
30
C. Audio error_Wrecked
audio/discontinuation
Voltage and speaker checking method in
case of audio error
A16
31
D. Function error_ No response in
remote controller, key error
Remote controller operation checking method A17
Continued from previous page
Copyright © 2013 LG Electronics. Inc. All rights reserved.
Only for training and service purposes
LGE Internal Use Only

LG 55LB5610 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	55 \
Display brightness	- cd/m²
Native aspect ratio	16:9
Native refresh rate	50 Hz
LED backlighting type	-
Display diagonal (metric)	139 cm
Motion interpolation technology	MCI (Motion Clarity Index) 100
Tuner type	Analog & digital
Digital signal format system	DVB-T
Audio system	Virtual Surround
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	- W

Weight and Dimensions

Depth (with stand)	255 mm
Height (with stand)	772 mm
Weight (with stand)	18400 g
Depth (without stand)	57 mm
Width (without stand)	1243 mm
Height (without stand)	725 mm
Weight (without stand)	18000 g
