ASSEMBLING AND PREPARING
Parts and buttons
Button Description
/ ( / ) Scrolls through the saved channels.
/ ( / )
Adjusts the volume level.
(
OK
)
Selects the highlighted menu option or confirms an input.
(
SETTINGS
)
Accesses the main menus, or saves your input and exits the menus.
(
INPUT
)
Changes the input source.
( )
Turns the power on or off.
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
SERVICE ONLY
IN 2
USB IN
COMPONENT IN / AV IN
VIDEO/
ANTENNA
IN /
CABLE IN
PB PR
Y
IN
1
R
AUDIO
L/MONO
Buttons
Screen
Speakers
Rear Connection
Panel
Side Connection
Panel
Intelligent Sensor
1
Power Indicator
Remote Control Sensor
For LN5100 series
