16
ENGLISH
Connecting
IR and Light Sensor
When you connect the c
able to the product, the feature for r
eceiving r
emote contr
ol signals is activated.
The IR and
light sensor is magnetic. Attach it to the fr
ont edge of the product for use.
Basic installation
[F
ront]
NOTE
•
The signal strength of the
IR and Light sensor will decrease if the sensor is not placed in fr
ont of the product.
15
