19
ENGLISH
Attaching the L
G Logo Bracket
Use one screw
, inser
ted fr
om behind, to attach the LG Logo Brack
et to the monitor
. You can position the logo accor
ding
to the monitor’
s direction.
When the monitor is in the horizontal position
When the monitor is in the vertical position
18
20
