14 Indoor Unit
Installation
Ceiling dimension and hanging bolt location
Unit:mm
TM/TN/TP/TM-A/TP-B Chassis
875(Ceiling opening)
787(Hanging bolt)
684
(Hanging bolt)
671
875
(Ceiling opening)
840 Unit size
840 Unit size
Unit:mm
TQ/TR Chassis
585~660(Ceiling opening)
517
461
517
585~660(Ceiling opening)
523
570
570
319
Ceiling board
Level gauge
Ceiling
• The dimensions of the paper model for installation are the same as those of the ceiling opening dimensions.
(Unit: mm)
TT Chassis
TU Chassis
1 285(Hanging bolt)
1 385(Ceiling opening)
50
250
600
50
466
(Ceiling opening)
1 180
448
600
250
965(Hanging bolt)
1 065(Ceiling opening)
50
50
860
448
306 400 4040
400 4040 306
354
(Hanging bolt)
466
(Ceiling opening)
354
(Hanging bolt)
410(Hanging bolt)
600
116
642 (Ceiling opening)
unit: mm
1 033 (Ceiling opening)
855 (Hanging bolt)
830
60
TS Chassis
4 Way
2 Way
TY Chassis
650
650
650
650
(Hanging bolt)
unit: mm
Round
1 Way
< Type : Round >
Tighten the screw as shown in the image so the
deco panel doesn’t move after the product has been
installed. (1 Spot)
Screws to tighten the deco panel are contained in
the indoor unit's accessory package.
