Names of parts
8
USB
AC IN
Kensington Security
System Connector
(Refer to page 14)
VIDEO
HDMI/DVI
RGB OUT
RGB 2 IN
RGB 1 IN
IR (Remote control sensor)
*
Do not block the IR port for normal
operation of remote control.
RS-232C
LAN
AUDIO IN
Connecting Part
* When using HDMI/USB connector, if the size of the jack connecting
to the connector is too big, they may not be connected. Please use
standard size jack.
Headphone port
To Next Page
