EXPLODED VIEW PARTS LIST
LOCA. NO PART NO DESCRIPTIONS
104 4980V00047B SUPPORTER,PCB
112 6341V29005A CPT ASSY,2426GF239AT 100HZ DY
2426GF239CB CPT SET, A68QCU259X V4M7ND *N.ALLIED,TELESTAR
2426GF239CG CPT SET, A68QCU259X V4T7ND *DRAGON
120 6400VA0025A SPEAKER,C163P01K1450 ESTEC 8 OHM 15/25
121 120-C76G SPEAKER,TWEETER C050TX-357K14 8 OHM 10/
122 3110V00084A CASE,MIDDLE SPEAKER
123 3550V00117A COVER,MIDDLE SPEAKER
124 120-C78G SPEAKER,WOOFER C130R06K1457 8 OHM 10W/
125 3110V00080A CASE,WOOFER
126 3550V00103A COVER,WOOFER
127 6401VF0035B SPEAKER ASSY,DOME CENTER
150 150-201S COIL,DEGAUSSING CU 29Ó 440T 102 OHM
153 6150Z-1340F DY,DC29SLFL2
170 170-844K CPT EARTH 29Ó 98T
300 3091V00281B CABINET ASSY
310 5020V00427A BUTTON,CONTROL
320 320-070G SPRING,COIL
330 5020V00426A BUTTON,POWER
340 4470V00019A GEAR ASSY, MOVING CTR SPK
400 3809V00207F BACK COVER ASSY (JACK)
3809V00207G BACK COVER ASSY (SCART)
501 4810V00259A BRACKET,MAIN
503 4810V00261A BRACKET,REAR A/V HIPS 2 PHONE
4810V00261C BRACKET,REAR A/V HIPS 2 SCART
510 6871VSM738A PWB ASSY,CPT MC006A CPT&VM
520 6871VMM637A PWB ASSY,MAIN (2 PHONE)
6871VMM637B PWB ASSY,MAIN (2 SCART)
530 6871VDM113A PWB ASSY,MAIN2 29Ó,W/O ST-BY,W-RAN
540 6871VSM726A PWB ASSY,WIDE RANGE
550 6871VSM617A PWB ASSY,DIGIT 100HZ
560 6871VSM694A PWB ASSY,MEMORY
570 6871VSM685A PWB ASSY,CONTROL
580 6871VSM686A PWB ASSY,TACT-SWITCH
600 6871VSM620A PWB ASSY,SIDE-A/V
700 0IGL120104A IC,CDS SENSOR MODULE(P1201-04)
913 332-229N SCREW ASSY
943 1PTF0403116 SCREW,TAP TITE D4.0 L16.0
P801 174-322D CORD,POWER W/FILTER L=300(179B)VDE
174-222S CORD,POWER
The components identified by mark is
critical for safety.
Replace only with part number specified.
