CONTROL LAY - OUT
7
PWB ASSEMBLY DISPLAY LAYOUT
PWB ASSEMBLY LAYOUT
※
MODEL DISPLAY AS DIAGNOSTIC TEST
DISPLAY Part Number
EBR33477201
EBR33640901 18:E8 Electric, NEO(D) LED
Gas, NEO(D) LED
18:98
EBR33640902
MAIN Part Number 7-SEG Display
NOTE
DISPLAY Part Number
EBR33477201
EBR33640901 18:E8 Electric, GAINT(D) LED
Gas, GAINT(D) LED
18:98
EBR33640902
MAIN Part Number 7-SEG Display
NOTE
※
MODEL AS DIAGNOSTIC TEST
