REPLACEMENT PARTS LIST
13
DLE2512W DLE2514W QTY
A500 CABINET ASSEMBLY 3091EL0003A 3091EL0003A 1
K610 MOTOR ASSEMBLY. WM 4681EL1002A 4681EL1002A 1
A520 BRACKET, BASE 4810EL3001A 4810EL3001A 2
A530 BRACKET, BASE 4810EL3009A 4810EL3009A 2
A540 LEG 4778EL3001A 4778EL3001A 4
K650 PULLEY ASSEMBLY, MOTOR 4561EL3002A 4561EL3002A 1
K640 SWITCH, MICRO 3W40025D 3W40025D 1
K510 BLOWER ASSEMBLY 5835EL1002A 5835EL1002A 1
K520 HOUSING ASSEMBLY (MECH), BLOWER 3661EL1001C 3661EL1001C 1
K530 DUCT ASSEMBLY 5209EL1006A 5209EL1006A 1
K550 THERMISTOR ASSEMBLY 6323EL2001B 6323EL2001B 1
K560 THERMOSTAT ASSEMBLY 6931EL3002A 6931EL3002A 1
K400 TUB, DRUM [BACK] 3044EL002C 3044EL002C 1
F200 DUCT ASSEMBLY 5209EL1001C 5209EL1001C 1
K250 ROLLER ASSEMBLY 4581EL3001A 4581EL3001A 2
F110 HEATER ASSEMBLY 5301EL1001E 5301EL1001E 1
F130 THERMOSTAT ASSEMBLY 6931EL3003D 6931EL3003D 1
F140 THERMOSTAT ASSEMBLY 6931EL3001E 6931EL3001E 1
A600 HARNESS, PWB 6877EL1007A 6877EL1007B 1
K100 TUB ASSEMBLY, DRUM 3045EL1002D 3045EL1002D 1
K140 SEAL 4036EL3001A 4036EL3001A 2
K120 LIFTER 4432EL1002B 4432EL1002B 3
K130 BELT, POLY-V 4400EL2001A 4400EL2001A 1
K210 TUB , DRUM [FRONT] 3044EL1001A 3044EL1001A 1
K221 LAMP ASSEMBLY 6913EL3002C 6913EL3002C 1
K250 ROLLER ASSEMBLY 4581EL3001A 4581EL3001A 2
K240 DUCT ASSEMBLY 5209EL1002A 5209EL1002A 1
K320 COVER, GUIDE 3550EL1006B 3550EL1006B 1
LG MODEL: TD-V10062E
,
TD-V10060E
Model P/No
DescriptionLOCAL
K340 SENSOR 6500EL3001A 6500EL3001A 2
K330 GUIDER, FILTER 4974EL1003B 4974EL1003B 1
K310 FILTERASSEMBLY, LINT 5231EL1003B 5231EL1003B 1
A390 FRAME ASSEMBLY 3211EL1005A 3211EL1005A 1
K620 CLAMP 4860EL3001A 4860EL3001A 2
A310 COVER, CABINET 3550EL0006A 3550EL0006A 1
A330 SWITCH ASSEMBLY, DOOR 6601EL3001A 6601EL3001A 1
A320 LATCH ASSEMBLY 4027EL1001A 4027EL1001A 1
A400 DOOR ASSEMBLY 3581EL0003B 3581EL0003A 1
A410 LATCH, HOOK 4026EL3007A 4026EL3007A 1
A460 GASKET 4986EL2004D 4986EL2004D 1
A210 TOP PLATE ASSEMBLY 3457ER1006E 3457ER1006E 1
A110 PANEL, CONTROL 3720EL0002A 3720EL0002A 1
A130 PWB (PCB) ASSEMBLY 6871EC1121C 6871EC1121C 1
A120 PWB (PCB) ASSEMBLY, DISPLAY 6871EC1120A 6871EC1120A 1
A700 RACK 3750EL1001B 3750EL1001B 1
A800 SIDE VENTING KIT 383EEL9001B 383EEL9001B 1
K350 CONNECTOR ASSEMBLY 6631EL3003B 6631EL3003B 1
CAUTION: Before replacing any of these components,
read the safety precautions in this manual.
¡Æ Note: S(Safety Parts), AL (Alternative parts)
