LG DLE7100W User Manual

2
TABLE OF CONTENTS
TABLE OF CONTENTS
3
PRODUCT FEATURES
4
SAFETY INSTRUCTIONS
5 IMPORTANT SAFETY INSTRUCTIONS
7 GROUNDING INSTRUCTIONS
8 CALIFORNIA SAFE DRINKING WATER AND
TOXIC ENFORCEMENT ACT
9
PRODUCT OVERVIEW
9 Parts
9 Accessories
10
INSTALLATION
10 Installation Overview
10 Product Specifications
11 Installation Location Requirements
11 Clearances
13 Leveling the Dryer
14 Reversing the Door
15 Installing the Side Vent Kit
16 Venting the Dryer
18 Connecting Gas Dryers
20 Connecting Electric Dryers
24 Final Installation Check
25 Installation Test (Duct Check)
27
OPERATION
27 Using the Dryer
28 Check the Lint Filter Before Every Load
28 Sorting Loads
28 Loading the Dryer
29 Control Panel
31 Cycle Guide
33 Cycle Settings and Options
35
SMART FUNCTIONS
35 Smart Diagnosis™ Function
36
MAINTENANCE
36 Regular Cleaning
37
TROUBLESHOOTING
37 FAQs: Frequently Asked Questions
37 User Support Videos
38 Before Calling for Service
45
WARRANTY (USA)
MFL67652515_en_171019.indd 2 2017-10-19 오전 11:36:07

LG DLE7100W Specifications

General

Color	white
Dryer Capactity	7.3 cubic feet
Number of Cycles	8
Cycle Selections	wrinkle care, delicate, speed dry, perm press, normal, heavy duty, freshen up, air dry, damp dry, cottons, very dry, casual, normal dry, 60 min cycle, 40 min cycle, 20 min cycle, sensor drying option, bulky/bedding, more time, less time
Options	wrinkle care, delicate, speed dry, perm press, normal, heavy duty, freshen up, air dry, damp dry, cottons, very dry, casual, normal dry, 60 min cycle
Stackable	no
Venting	true, vented
Temperature Settings	3
Temperature Selections	high, medium, low
Temperature Control	no
Control Type	dial, touchpad
Delay Start	no
Child Lock	yes
Cycle Signal	yes
Interior Light	no
Drying Rack	no
Moisture Sensor Option	yes
Steam	no
Smart Home	no
Voltage	240 volts
Current	30 amperes

Weight and Dimensions

Depth	29 1/2 inches
Height	44 5/16 inches
Width	27 inches
Net Weight	128 pounds
