LG DLE7100W User Manual

28
OPERATION
Check the Lint Filter Before
Every Load
Always make sure the lint filter is clean before starting
a new load; a clogged lint filter will increase drying
time. To clean, pull the lint filter straight up and roll
any lint off the filter with your fingers. Do not rinse or
wash the filter to remove lint. Push the lint filter firmly
back into place. See Regular Cleaning for more
information.
Always ensure the lint filter is properly installed before
running the dryer. Running the dryer with a loose or
missing lint filter will damage the dryer and articles in
the dryer.
Lint Filter
Sorting Loads
Fabric Care Labels
Most articles of clothing feature fabric care labels that
include instructions for proper care.
Fabric Care Labels
Heat setting
High
Medium Low
No heat/air
Tumble dry
Dry
Normal
Permanent Press/
wrinkle resistant
Gentle/
delicate
Do not
tumble dry
Do not dry
(used with do not wash)
Group Similar Items
For best results, sort clothes into loads that can be
dried with the same drying cycle.
Different fabrics have different care requirements, and
some fabrics will dry more quickly than others. For
best fabric care results, always dry fabrics with similar
care requirements together.
Loading the Dryer
WARNING
To reduce the risk of fire, electric shock, or
injury to persons when using this appliance,
follow basic precautions, including the
following:
•
Check all pockets to make sure that they are
empty. Items such as clips, pens, coins, and
keys can damage both your dryer and your
clothes. Flammable objects such as lighters
or matches could ignite, causing a fire.
Failure to do so may result in fire, explosion, or
death.
•
Never dry clothes that have been exposed
to oil, gasoline, or other flammable
substances. Washing clothes will not
completely remove oil residues. Failure to
obey this warning may result in fire, explosion,
or death.
NOTE
Loading Tips
•
Combine large and small items in the same
load.
•
Damp clothes will expand as they dry. Do not
overload the dryer; clothes require room to
tumble and dry properly.
•
Close zippers, hooks, and drawstrings to
prevent these items from snagging or tangling
on other clothes.
MFL67652515_en_171019.indd 28 2017-10-19 오전 11:36:14

LG DLE7100W Specifications

General

Color	white
Dryer Capactity	7.3 cubic feet
Number of Cycles	8
Cycle Selections	wrinkle care, delicate, speed dry, perm press, normal, heavy duty, freshen up, air dry, damp dry, cottons, very dry, casual, normal dry, 60 min cycle, 40 min cycle, 20 min cycle, sensor drying option, bulky/bedding, more time, less time
Options	wrinkle care, delicate, speed dry, perm press, normal, heavy duty, freshen up, air dry, damp dry, cottons, very dry, casual, normal dry, 60 min cycle
Stackable	no
Venting	true, vented
Temperature Settings	3
Temperature Selections	high, medium, low
Temperature Control	no
Control Type	dial, touchpad
Delay Start	no
Child Lock	yes
Cycle Signal	yes
Interior Light	no
Drying Rack	no
Moisture Sensor Option	yes
Steam	no
Smart Home	no
Voltage	240 volts
Current	30 amperes

Weight and Dimensions

Depth	29 1/2 inches
Height	44 5/16 inches
Width	27 inches
Net Weight	128 pounds
