17INSTALLATION
ENGLISH
WARNING
THE DRYER DOOR IS VERY LARGE AND
HEAVY. Failure to follow the instructions
below can result in damage to the dryer,
property damage or injury to persons.
• To avoid damage to the dryer or the door,
support the door with a stool or box that fits
under the door, or have an assistant support
the weight of the door.
• Always reverse the door BEFORE stacking
the dryer on top of the washer.
• Avoid dropping the door to avoid damage to
the door or the floor.
7
Move the door to the left side and line up the
holes in the hinge with the holes in the cabinet.
Hinge hole
CAUTION
Be sure to support the weight of the door
before inserting the hinge screws.
8
Hold the hinge in place while inserting the
two hinge screws (to prevent the door from
dropping).
Hinge Screw
9
Insert the latch on the right side and install the
latch screws.
Latch
Screw
10
Insert the four decorative screws on the right
side.
Decorative
Hinge
Screw
11
Check that the door closes and latches
properly.
Swing Door

LG DLGX4001B Specifications

General

Type	front load; gas
Color	black steel; white (w), black steel (b)
Dryer Capactity	7.4 cu. ft.
Number of Cycles	12
Number of Options	12; more time, less time, damp dry signal, wrinkle care, control lock, wi-fi, energy saver, turbosteam™, reduce static, remote start, drum light, signal
Drying Levels	very dry, more dry, normal dry, less dry, damp dry
Venting	vented; electric: 4 way venting / gas: 3 way venting
Temperature Settings	high, med.high, medium, low, ultra low; 5
Control Panel	digital and knobs
Cycle Signal	yes
Interior Light	yes
Drying Rack	no
Sensor Dry Option	yes
Sanitize Option	yes
Steam	turbosteam™; yes
Smart Home	yes
Remote Control	yes
Wi-Fi	yes
Voltage	120 volts
Current	15

Weight and Dimensions

Depth	30 1/8 inch
Height	39 inch
Width	27 inch
Net Weight	139.3 lbs
