LG DLGX4001B User Manual

34 OPERATION
Check the Lint Filter Before
Every Load
Always make sure the lint filter is clean before
starting a new load; a clogged lint filter will increase
drying time. To clean, pull the lint filter straight up and
roll any lint off the filter with your fingers. Push the lint
filter firmly back into place. See Regular Cleaning
for more information.
Always ensure the lint filter is properly installed
before running the dryer. Running the dryer with a
loose or missing lint filter will damage the dryer and
articles in the dryer.
Lint Filter
Sorting Laundry
Fabric Care Labels
Many articles of clothing include a fabric care label.
Using the chart below, adjust the cycle and option
selections to care for your clothing according to the
manufacturer’s recommendations.
Tumble dry
Dry Gentle/delicate
Normal
Do not tumble
dry
Permanent
Press/ wrinkle
resistant
Do not dry (used
with do not wash)
Heat setting
High Low
Medium No heat/air
Grouping Similar Items
For best results, sort clothes into loads that can be
dried with the same drying cycle.
Different fabrics have different care requirements,
and some fabrics will dry more quickly than others.
Loading the Dryer
WARNING
To reduce the risk of fire, explosion, electric
shock, injury to persons, and death when
using this appliance, follow basic precautions,
including the following:
• Check all pockets to make sure that they are
empty. Items such as clips, pens, coins, and
keys can damage both the dryer and your
clothes. Flammable objects such as lighters or
matches could ignite, causing a fire.
• Never dry clothes that have been exposed to
oil, gasoline, or other flammable substances.
Washing clothes will not completely remove oil
residues.
NOTE
Loading Tips
• Combine large and small items in the same load.
• Damp clothes will expand as they dry. Do not
overload the dryer; clothes require room to tumble
and dry properly.
• Use mesh laundry bags to separate clothes with
zippers, hooks, straps, and drawstrings to prevent
them from catching on or tangling with other clothes
or damaging the lint filter.

LG DLGX4001B Specifications

General

Type	front load; gas
Color	black steel; white (w), black steel (b)
Dryer Capactity	7.4 cu. ft.
Number of Cycles	12
Number of Options	12; more time, less time, damp dry signal, wrinkle care, control lock, wi-fi, energy saver, turbosteam™, reduce static, remote start, drum light, signal
Drying Levels	very dry, more dry, normal dry, less dry, damp dry
Venting	vented; electric: 4 way venting / gas: 3 way venting
Temperature Settings	high, med.high, medium, low, ultra low; 5
Control Panel	digital and knobs
Cycle Signal	yes
Interior Light	yes
Drying Rack	no
Sensor Dry Option	yes
Sanitize Option	yes
Steam	turbosteam™; yes
Smart Home	yes
Remote Control	yes
Wi-Fi	yes
Voltage	120 volts
Current	15

Weight and Dimensions

Depth	30 1/8 inch
Height	39 inch
Width	27 inch
Net Weight	139.3 lbs
