Connecting to the TV
Connecting with an Optical Cable
Transmit your TV’s audio to the product by connecting it to the TV with an optical cable. You can add a variety of
3Deffectstotheoriginalaudiotolltheroomwithadeep,richsound.
Watching TV after connecting with an optical cable
a Ifthedigitalcableterminalhasacover,rstremovethecoversfrombothends.
b Using an optical cable, connect the OPTICAL IN terminal on the back of the product to the Optical Digital
Output (OPTICAL OUT) terminal on the TV as shown in the picture.
Connecting to the TV

LG DS75Q Specifications

General

Audio decoders	DTS Digital Surround, DTS-HD HR, DTS-HD Master Audio, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
RMS rated power	380 W
Audio output channels	3.1.2 channels
Soundbar mode control	Yes
Audio sample rate (24bit)	96 kHz
Soundbar speaker RMS power	- W
Subwoofer location	Separate
Subwoofer connectivity	Wireless
Display type	LCD
Product color	Steel
Audio formats supported	AAC, AAC+, FLAC, LPCM, MP3, OGG, WAV, WMA
Consumer Electronics Control (CEC)	SimpLink
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10)
Cables included	HDMI, Optical
Number of products included	1 pc(s)
Wi-Fi	No
Bluetooth codec	AAC, SBC
Bluetooth version	4.2
Number of HDMI outputs	1
AC input voltage	200 - 240 V
AC input frequency	50 - 60 Hz
Soundbar power consumption	38 W
Power consumption (standby)	0.5 W
Subwoofer power consumption	33 W
Package depth	247 mm
Package width	1027 mm
Package height	470 mm
Package weight	13700 g

Weight and Dimensions

Depth	119 mm
Width	890 mm
Height	65 mm
Soundbar weight	3790 g
Subwoofer depth	290 mm
Subwoofer width	180 mm
Subwoofer height	394 mm
Subwoofer weight	5800 g
