Connecting with an HDMI Cable

You can transmit TV audio to the product by connecting the TV to the product with an HDMI cable. Add a variety

of3Deffectstotheoriginalaudiotolltheroomwithadeep,richsound.

Watching TV after connecting with an HDMI cable

a Using the HDMI cable, connect the HDMI OUT (TV eARC/ARC) terminal on the back of the product to the

HDMI IN (ARC) terminal on the TV as shown in the picture.

b Press the Function button repeatedly until “OPT/HDMI ARC” appears on the status display.

c Press the Settings button on the TV remote control to enter the [Speaker] menu and set the output speaker

to [HDMI ARC]. Settings and menu items may vary depending on the TV manufacturer.

d When the TV is properly connected to the product, “ARC” or “E-ARC” will appear on the status display.

Note

• E-ARC supports high-quality audio such as DTS-HD Master Audio™, DTS:X®, Dolby TrueHD, and Dolby Atmos®.

• If you wish to use Dolby Atmos® or DTS:X®, the connected device and its content should support Dolby Atmos®

or DTS:X®.

• Ensure that your TV supports the eARC function before you turn on eARC from the Settings menu. For more

information on how to use this function, please refer to your TV’s user manual. Settings may vary depending on

the TV.

• UseacertiedcablewiththeHDMIlogo.

Other manuals for LG DS75Q

Questions and Answers:

Need help?

Do you have a question about the LG DS75Q and is the answer not in the manual?

General

Audio decoders	DTS Digital Surround, DTS-HD HR, DTS-HD Master Audio, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
RMS rated power	380 W
Audio output channels	3.1.2 channels
Soundbar mode control	Yes
Audio sample rate (24bit)	96 kHz
Soundbar speaker RMS power	- W
Subwoofer location	Separate
Subwoofer connectivity	Wireless
Display type	LCD
Product color	Steel
Audio formats supported	AAC, AAC+, FLAC, LPCM, MP3, OGG, WAV, WMA
Consumer Electronics Control (CEC)	SimpLink
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10)
Cables included	HDMI, Optical
Number of products included	1 pc(s)
Wi-Fi	No
Bluetooth codec	AAC, SBC
Bluetooth version	4.2
Number of HDMI outputs	1
AC input voltage	200 - 240 V
AC input frequency	50 - 60 Hz
Soundbar power consumption	38 W
Power consumption (standby)	0.5 W
Subwoofer power consumption	33 W
Package depth	247 mm
Package width	1027 mm
Package height	470 mm
Package weight	13700 g
