ASSEMBLING AND PREPARING
y
This illustration depicts the general model of
connection. Your monitor may differ from the
items shown in the picture.
y
Do not carry the product upside down holding
only the stand base. The product may fall
and get damaged or injure your foot.
CAUTION
Detaching the Stand Base
1
Place the Monitor set with the screen side
down on a flat and cushioned surface.
E2742V
Stand Base
Stand Base
Stand Body
Stand Body
Stand Base
Stand Body
Stand Body
Pull out the Stand Body and Stand Base from
the monitor set.
Turn the screw to the left with a coin.
Pull out the Stand Base.
1
2
3
Turn the screw to the left with a coin.
Pull out the Stand Base from the Stand Body.
Remove two screws and pull out the Stand
Body from the monitor set.
1
2
3
2
E2242V/E2342V/E2442V
