LG E2350V User Manual

20
On Screen Display(OSD) Selection and Adjustment
Main menu Sub menu Description
CLOCK
PHASE
OVERSCAN
To minimize any vertical bars or
stripes visible on the screen
background.
The horizontal screen size will also
change.
To adjust the focus of the display.
This item allows you to remove any
horizontal noise and clear or sharpen
the image of characters.
Removes noise that may occur at the edges
of an image when HDMI is connected to an
external device. When ON is selected, the
image size is reduced to prevent noise.
When OFF is selected, the original image
size is maintained regardless of noise.
(Only for HDMI input)
HORIZONTAL
VERTICAL
To move image left and right.
To move image up and down.
Exit : Exit
: Decrease
: Increase
: Select another sub-menu
: Restart to select sub-menu
D-SUB/DVI-D input
HDMI input
VOLUME To adjust the volume of headphone/
Earphone.
(Only for HDMI input)
Exit : Exit
: Decrease
: Increase
: Mute
: Restart to select sub-menu
HDMI input

LG E2350V Specifications

General

Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Display diagonal	23 \
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
HDCP	Yes
DVI-I ports quantity	0
Product color	Black
Market positioning	-
Power requirements	90 - 264 Vac, 47 - 63 Hz
Power consumption (standby)	1 W
Power consumption (typical)	28 W
LED indicators	Stand-by

Weight and Dimensions

Bezel width (side)	3300 mm
Depth (with stand)	198 mm
Width (with stand)	559.8 mm
Height (with stand)	428.1 mm
Depth (without stand)	39.9 mm
Width (without stand)	529.8 mm
Height (without stand)	354 mm
Weight (without stand)	2860 g
