LG F1480RD User Manual

26
Tub Clean is a special cycle to clean the inside of the washing machine.
A higher water level is used in this cycle at higher spin speed. Perform this cycle regularly.
1. Remove any clothing or items from the
washer and close the door.
2. Open the dispenser drawer and add Anti
limescale(e.g. Calgon) to the main wash
compartment.
3. Close the dispenser drawer slowly.
4.
Power On and then press and hold Spin
and Temp. button for 3 seconds. then “ ”
will be displayed on the LED display.
5. Press the Start/Pause button to start.
6. After the cycle is complete, leave the door
open to allow the washer door opening,
flexible gasket and door glass to dry.
•
“Door Lock” - For safety reasons, the
door will lock while machine is in use and the
“Door Lock” icon will light up. You can safely
open the door after the “Door Lock” icon
turns off.
•
While "Detecting" is shown on the
display the washing machine rotates slowly
and detects how much laundry is loaded in
the drum.
It will take a short time.
A
B
■ Tub Clean
■ Door Lock & Detecting
How to use washer
NOTE
• Do not add any detergent to the detergent compartments.
• Excessive suds may generate and leak from the washer.
CAUTION
• If there is a child, be careful not to leave the door open for too long.

LG F1480RD Specifications

General

Energy consumption washing per cycle	- kWh
Water consumption washing & drying per cycle	95 L
Energy consumption washing & drying per cycle	7.29 kWh
Washing class	A
Drum volume	65 L
Display type	LED
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Drying capacity	6 kg
Washing capacity	9 kg
Delay start (max)	19 h
Maximum spin speed	1400 RPM
Minimum spin speed	400 RPM
Noise level (spin)	69 dB
Number of washing programs	13
Door opening angle	170 °

Weight and Dimensions

Depth	640 mm
Width	600 mm
Height	850 mm
Weight	72000 g
Door opening diameter	350 mm
