LG F1480RD User Manual

9
Installation
■ Removing packing
1. Remove the cardboard box and
styrofoam packing.
2. Lift the washing machine and remove
the base packing.
3. Remove the tape securing the power
supply cord and drain hose.
4. Remove the inlet hose from the drum.
1. Unscrew the 4 bolts with
the spanner supplied.
2. Take out the 4 bolts along with the
rubber bungs by slightly twisting the
bung.
3. Close the holes with the caps supplied.
To prevent internal damage during transport, the 4 special bolts are locked.
Before operating the washer, remove the bolts along with the rubber bungs.
If they are not removed, it may cause heavy vibration, noise and malfunction.
■ Removing transit bolts
Transit bolt
WARNING
• Packaging material (e.g. Films, Styrofoam) can be dangerous for children.
There is a risk of suffocation ! Keep all packaging well away from children.
NOTE
• Keep the spanner provided for
future use.
NOTE
• Keep the transit bolts for future use.
Spanner
Washer
Base Packing

LG F1480RD Specifications

General

Energy consumption washing per cycle	- kWh
Water consumption washing & drying per cycle	95 L
Energy consumption washing & drying per cycle	7.29 kWh
Washing class	A
Drum volume	65 L
Display type	LED
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Drying capacity	6 kg
Washing capacity	9 kg
Delay start (max)	19 h
Maximum spin speed	1400 RPM
Minimum spin speed	400 RPM
Noise level (spin)	69 dB
Number of washing programs	13
Door opening angle	170 °

Weight and Dimensions

Depth	640 mm
Width	600 mm
Height	850 mm
Weight	72000 g
Door opening diameter	350 mm
