LG flatron L1760TR User Manual

- 20 -
EXPLODED VIEW PARTS LIST
010
020
030
040
050
060
070
080
090
100
110
120
130
140
30919L0031E Cover Assembly, L1760 . 17" L1760TR
30919L0031F Cover Assembly, L1760 . 17" L1760 "E"-CKD
30919L0032D Cover Assembly, L1960TR LM57D 19" L1960TR CABINET
30919L0032H Cover Assembly, L1960 LM57D 19" L1960TR D-CKD
EAJ32188801
LCD,Module-TFT, LM170E03-TLB3 DRIVER 17.0INCH 1280X1024 300CD COLOR 72% 5/4 800 VS 1 5MS, 160/160, 4LAMP, 2CH-LVDS
EAJ32188901 LCD,Module-TFT, LM190E08-TLB5 DRIVER 19INCH 1280X1024 300CD COLOR 72% 5/4 800 : 1 P4 FACTORY 5MS, 2CH-LVDS, 160/160, 4LAMP
or EAJ32189001 LCD,Module-TFT, LM190E08-TLB2 DRIVER 19.0INCH 1280X1024 300CD COLOR 72% 5/4 800:1 P7 FACTORY 5MS, 160/160, 2CH-LVDS, 4LAMP
3809900209A Cover Assembly, L1760 LM57C 17" BC ASSEMBLY
3809900209B Cover Assembly, L1760 . 17" L1760 BACK COVER CKD
3809900210G Cover Assembly, L1960TR LM57D 19" L1960TR 2MS LPL
3809900210L Cover Assembly, L1960TR LM57D 19" L1960TR G-CKD
3043900054A Base Assembly, L1760, L1960 . BASE TOP ASSY
3043900054B Base Assembly, ASSY L1760, L1960 LM57D L1760, L1960 STAND BASE TOP ASSY(CKD)
3043900055A Base Assembly, L1760, L1960 . BASE BOTTOM ASSY
3043900055B Base Assembly, ASSY L1760, L1960 LM57D L1760, L1960 BASE BOTTOM ASSY(CKD)
35509K0301A Cover, L1760 TOP REAR DOOR
35509K0301B Cover, MOLD ABS HF-350 L1760 ABS L1760 DOOR(CKD)
35509K0302A Cover, L1960 TOP REAR DOOR
35509K0302B Cover, MOLD ABS HF-350 L1960 ABS L1960 DOOR(CKD)
4940900029A Knob, MAIN 4KEY L1760 .
4940900029B Knob, MOLD ABS HF-350 SUB 4KEY L1760, L1960 .-CKD
68719STA70A PCB Assembly,Sub, SUB T.T LM57C L1X60T AXRDQP -
68719STA70B PCB Assembly,Sub, SUB T.T LM57D L1x60TQ KxxxQPN NT CKD
35509K0310A Cover, L1760 PANEL INVERTER VACUUM
35509K0310B Cover, MOLD PS L1760,L1960 HIPS L1760, L1960 INVERTER VACUUM(CKD)
6633TZA019E Inverter,DC/AC, FIF1742-50A 12.0TO12.0 800V 7MA 2 YES -L1760TR
or 6633TZA019F
Inverter,DC/AC, FIF1742-50A_PWM 11.4VTO12.6V,11.4VTO12.6V,11.4VTO12.6V 800V 7MA 2 YES Bin3/4 FRONTEK-L1760TR
66339A0020A Inverter,DC/AC, FIF1742-50B 11.5VTO12.5V,11.5VTO12.5V,11.5VTO12.5V 800V 7.3A 4 YES PWM DIMMING 19INCH PB FREE-L1960TR
or 66339A0020C Inverter,DC/AC, FIF1742-50B_PWM 11.5VTO12.5V,11.5VTO12.5V,11.5VTO12.5V 800V 7.3A 4 YES PWM DIMMING 19INCH PB FREE Bin3/4 FRONTEK-L1960TR
EBU31069501 Main Total Assembly, L1760TQ-BFQ BRAND LM57D
EBU31069502 Main Total Assembly, L1760TQ-BFQ BRAND LM57D NT CKD
33139L7044A Main Total Assembly, L1960TQ BRAND LM57D
33139L7044B Main Total Assembly, L1960TQ BRAND LM57D NT CKD
49509S0039A Plate, SHIELD INVERTER LX60.-L1760TR
49509S0039B Plate, PRESS SPTE 0.5 SHIELD SPC L1760 INVERTER SHIELD(CKD)
49509S0041A Plate, SHIELD INVERTER L1960
49509S0041B Plate, PRESS SPTE 0.3 SHIELD SPC L1960 INVERTER SHIELD(CKD)
49519S0043A Plate Assembly, FRAME METAL BRACKET
49519S0043B Plate Assembly, ASSY L1760, L1960 METAL BRACKET ASSY(CKD)
6410TEW010A
Power Cord, CEE,LP-34A&H05VV-FX3C,LS-60_1.87M_BLK LP-34A LS-60 1.87M - 250V 16A H05VV-F 3X0.75MM2 BLACK VDE SEMKO N LONGWELL COMPANY-For Europe
EAD30470701
Power Cord, LP-42 LS-60 1.87M NONE 250V 10A H05VV-F 0.75MMX3C BLACK SII N LONGWELL-For Israel
Description
Part No.
Ref. No.
* Note: Safety mark
