LG flatron L1760TR User Manual

- 21 -
DATE: 2006. 10. 16.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C101 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C102 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C
C103 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C104 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C105 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C106 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C107 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C108 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C109 0CC270CK41A C1608C0G1H270JT 27pF 5% 50V
C110 0CC270CK41A C1608C0G1H270JT 27pF 5% 50V
C111 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C112 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16V
C113 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C114 0CK224CF56A 0603B224K160CT 220nF 10% 16V
C115 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C116 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C118 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C119 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C120 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C121 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C122 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C123 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C124 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C125 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C126 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C127 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C128 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C129 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C130 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C131 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C132 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C133 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C134 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C135 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C137 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C138 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C401 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C402 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C403 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C
C404 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V
C405 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C406 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C410 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C413 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C414 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C415 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C416 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C417 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C418 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C419 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C420 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C421 0CK104CK56A 0603B104K500CT 100nF 10% 50V
DATE: 2006. 10. 16.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C422 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C423 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C424 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C425 0CC680CK41A C1608C0G1H680JT 68pF 5% 50V
C426 0CC680CK41A C1608C0G1H680JT 68pF 5% 50V
C427 0CC680CK41A C1608C0G1H680JT 68pF 5% 50V
C428 0CC680CK41A C1608C0G1H680JT 68pF 5% 50V
C429 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C430 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C431 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C501 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C502 0CE107EF610 KMG16VB100M 100uF 20% 16V 12
C503 0CE107EF610 KMG16VB100M 100uF 20% 16V 12
C504 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C505 0CE107EF610 KMG16VB100M 100uF 20% 16V 12
C506 0CE107EF610 KMG16VB100M 100uF 20% 16V 12
C507 0CE107EF610 KMG16VB100M 100uF 20% 16V 12
C508 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C509 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C510 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C511 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C512 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C513 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C514 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C515 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C516 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C517 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C518 0CK102CK56A 0603B102K500CT 1nF 10% 50V X
C519 0CK102CK56A 0603B102K500CT 1nF 10% 50V X
C520 0CK102CK56A 0603B102K500CT 1nF 10% 50V X
C521 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C522 0CE107EF610 KMG16VB100M 100uF 20% 16V 12
C523 0CE107EF610 KMG16VB100M 100uF 20% 16V 12
C524 0CE107EF610 KMG16VB100M 100uF 20% 16V 12
C525 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
D404 0DD184009AA KDS184 KDS184 TP KEC - 85V -
D405 0DSIH00018A ENKMC2837-T112 1.2V 85V 300M
D406 0DSIH00018A ENKMC2837-T112 1.2V 85V 300M
D407 0DSIH00018A ENKMC2837-T112 1.2V 85V 300M
D408 0DSIH00018A ENKMC2837-T112 1.2V 85V 300M
D409 0DSIH00018A ENKMC2837-T112 1.2V 85V 300M
D410 0DSIH00018A ENKMC2837-T112 1.2V 85V 300M
D411 0DSIH00018A ENKMC2837-T112 1.2V 85V 300M
D412 0DSIH00018A ENKMC2837-T112 1.2V 85V 300M
D413 0DD184009AA KDS184 KDS184 TP KEC - 85V -
D416 0DSIH00018A ENKMC2837-T112 1.2V 85V 300M
D417 0DSIH00018A ENKMC2837-T112 1.2V 85V 300M
D418 0DSIH00018A ENKMC2837-T112 1.2V 85V 300M
D419 0DSON00138A MMBD301LT1G 600MV 30V - - 1.
D420 0DSON00138A MMBD301LT1G 600MV 30V - - 1.
D501 0DRON00268A MBRS190T3G 750MV 90V 2A - -
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
DIODEs
