LG GSXV90MCDE User Manual

19
INSTALLATION
ENGLISH
3 Use the spanner a to fasten the keeper nut by
turning it to the right.
NOTE
• Leveling the doors may not be possible when the
floor is not leveled, or is of weak or poor
construction.
• The refrigerator is heavy and should be installed
on a rigid and solid surface.
• Some timber flooring may cause levelling
difficulties if it flexes excessively.
Turning on the Power
Connecting the Appliance
After installing the appliance, connect the power
plug into the outlet socket. Do not double up with
other appliances on the same outlet.
NOTE
• After connecting the power supply cord (or plug)
to the outlet, wait 3 or 4 hours before you put
food into the appliance. If you add food before
the appliance has cooled completely, your food
may spoil.
• To turn off the appliance, disconnect the power
plug from the socket outlet.
Moving the Appliance for
Relocation
Preparing for Relocation
1 Remove all food from inside the appliance.
2 Pull the power plug out, insert and fix it into the
power plug hook at the rear or on top of the
appliance.
3 Tape parts such as shelves and the door handle
to prevent from falling off while moving the
appliance.
4 Move the appliance with more than two people
carefully. When transporting the appliance
over a long distance, keep the appliance
upright.
5 After installing the appliance, connect the
power plug into a mains outlet socket and
switch it on.
global_main.book.book Page 19 Monday, May 3, 2021 1:51 PM

LG GSXV90MCDE Specifications

General

Door hinge	Left/right
Control type	Touch, Wireless
Display type	LED
Door assembly	-
Product color	Black
Product design	American door
Built-in display	Yes
Door gasket type	Push-in gasket
Housing material	Metal
Shelves material	Tempered glass/Plastic
Shelf finish type	Metallic frame
Custom panel-ready	No
Appliance placement	Freestanding
Refrigerating medium	R600a
Number of compressors	1
Current	2 A
Connected load	325 W
Power plug type	Type G
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	350 kWh
Noise level	36 dB
Climate class	T
Cooling system	Dynamic (fan-assisted)
Water filter type	Faucet water filter
Water supply type	External water supply
Total net capacity	635 L
Water tank capacity	- L
Total gross capacity	674 L
Minimum operating temperature	16 °C
Fridge net capacity	416 L
Fridge gross capacity	424 L
Fridge temperature range	1 - 7 °C
Number of vegetable drawers	2
Fridge number of shelves/baskets	4
Star rating	4*
Freezer position	Side-placed
Freezing capacity	12 kg/24h
Freezer net capacity	219 L
Freezer gross capacity	250 L
Freezer temperature (min)	-23 °C
Storage time during power failure	2 h
Cord length	1.9 m
Package depth	770 mm
Package width	972 mm
Package height	1891 mm
Package weight	152000 g
Wine rack	Yes - 4 Bottles
LED indicators	Temperature, WLAN
Overall height	1860 mm
Country of origin	China
Number of drawers	2 drawer(s)
Dimensions (WxDxH)	913 x 735 x 1790 mm
Power requirements	Mains
Cooling system type	Total No Frost
Operating temperature (T-T)	16 - 43 °C
Installation compartment dimensions (WxDxH)	1013 x 670 x 1840 mm
Doesn't contain	Chlorofluorocarbon (CFC), Hydrofluorocarbon (HFC)
Quantity per pack	1 pc(s)
UK Trade Tariff code	8418102099

Weight and Dimensions

Depth	735 mm
Width	913 mm
Height	1790 mm
Weight	141000 g
Installation compartment depth	670 mm
Installation compartment width	1013 mm
Installation compartment height	1840 mm
