2 Connecting
Connecting 19
Connecting
2
Organizing cables
You can organize the cable with cable ties.
y
After all connections are completed, you can
arrange cables as needed.
y
We recommend to use the HDMI cable
supplied with this unit.
If another HDMI cable is used, it may not be
possible to arrange it with this unit.
,
Note
Connecting the AC
Adapter
Connect the unit to the power supply with the
supplied AC adapter.
1. Connect the supplied AC power cord to the AC
adapter.
2. Connect the AC adapter cable to DC IN adapter
input.
3. Plug the AC power cord into an AC outlet.
Only use the AC adapter supplied with this
device. Do not use a power supply from another
device or manufacturer. Using any other power
cable or power supply may cause damage to the
device and void your warranty.
>
Caution
To Next Page
