9
PARTS OF YOUR DISHWASHER
PP
AARRTTSS OOFF YYOOUURR DDIISSHHWWAASSHHEERR
Control Panel
Door Handle
Front Cover
Lower Cover
Leveling Foot
Side Cabinet
Base
Top Spray Arm
Upper Spray Arm
Removable Tines
Lower Spray Arm
Detergent & Rinse Aid Dispenser
Vapor Vent Cover
Upper Rack
Cutlery Basket
Lower Rack
Top Display
Power Button
Specifications
�Power supply: 120V, 60 AC only, minimum 15A circuit breaker.
�Water Pressure: 20 - 120 psi (140 - 830 kPa)
�Size (W
X
D
X
H): 23 7/8
″″
X
25
″″
X
33 7/8
″″
(606mm
X 635mm X 860mm)
�Inlet Water Temperature: 120(49)
�Weight: 115 Ibs. (52
)
The appearance and specifications are subject to change without
manufacturer’s notice.
