10 PRODUCT OVERVIEW
Interior Parts
10
11
5
9
2
8
1
3
4
7
1
Top Wash Impeller
2
Upper Spray Arm
3
Lower Spray Arm
4
Filtration System
Detergent and Rinse Aid Dispenser
6
Drying Vent Cover
Tub Light (some models)
8
Cutlery Rack (some models)
Upper Rack
10
Silverware Basket
Lower Rack (appearance may vary)
NOTE
• The silverware basket ships installed at the back
of the bottom rack. For best performance, install it
along the right side as shown in the Interior Parts
section.
• Remove all packing materials from the exterior
and interior of the dishwasher before installing the
appliance.
2
3
• Press the tab to remove the cable tie by hand.
Cutting the tie with a knife or scissors may damage
the rack or the silverware basket.
Accessories
Included Accessories
Installation
brackets
(2ea)
Wood screws
(4ea)
Hose clamp
(1ea)
