- 58 -
1) Ice maker doesn’t making Ice Cubes.
1
Check if Ice Maker is turned ON
No Checking flow Result & SVC Action
Result SVC Action
ON Go to step #2
OFF
1) Turn ON.
2) Execute I/Maker TEST MODE.
3) Check if tray ice was filled with water
after I/Maker TEST MODE:
YES ?Explain to the customer
NO ?Go to step #2
2
1-. Press ICE PLUS and FREEZER TEMP
keys.
2-. Check if Ice Maker Sensor error or
Ice Maker Kit error are present.
Result SVC Action
Error Displayed Proceed according displayed error.
No Error Displayed Go to step #3
3
1-Execute I/Maker TEST MODE.
2-. Wait until TEST MODE Finish.
3-. Check voltage between Purple and
Blue wires
Result SVC Action
110~120VAC Go to step #4
0~10VAC Replace Main PCB
TEST
BUTTON
8.8 Troubleshooting Without Error Display
To Next Page
