LG LMHM2237ST User Manual

- 27 -
MAINTENANCE
OVEN LIGHT REPLACEMENT
1. Unplug the oven or turn off power at the main
power supply and wear gloves.
2. Remove the vent cover mounting screw.
(1 outside screws)
3. Slide vent grille left, then lift out to remove.
4.
Remove the cover screw slide the cover to left
and then lift up the bulb holder.
5. Replace the bulb with a 30 watt appliance bulb.
6.
Replace the bulb holder and screw.
7. Slide in vent grille and replace the mounting screw.
Replace the mounting screws. Turn the power
back on at the main power supply.
COOKTOP/NIGHT LIGHT
REPLACEMENT
3. Replace the LED Lamp board.
4. Replace the LED Lamp cover and mounting
screws.
5. Turn the power back on at the main power supply.
*It is recommended that the cooktop lamp be replaced
by a qualified service technician.
2. Remove the LED lamp cover mounting screws.
1. Unplug the oven or turn off power at the
main power supply.
6.
Slide in vent grille and replace the mounting screw.
Turn the power back on at the main power supply
and set the clock.
5. Slide a new charcoal filter into place.
4. Remove the old filter.
1
2
1
2

LG LMHM2237ST Specifications

General

Style	over the range
Color	stainless steel
Total Capacity	2.2 cu. ft.
Convection	no
Power Levels	10
Fan Speeds	4
Venting Type	convertible
Sensor Cooking	yes
Quick Start	yes
Control Type	smoothtouch™ glass controls
Timer	yes
Interior Light	led; yes
Microwave Power	1, 000 watts
Voltage	120 volts
Current	15

Weight and Dimensions

Depth	15 7/8 inch
Height	17 15/16 inch
Width	29 7/8 inch
Net Weight	73.5-75.4 lbs.
