LG LMV2031BD User Manual

- 27 -
MAINTENANCE
OVEN LIGHT REPLACEMENT
1. Unplug the oven or turn off power at the main
power supply and wear gloves.
2. Remove the vent cover mounting screw.
(1 outside screws)
3. Slide vent grille left, then lift out to remove.
4.
Remove the cover screw slide the cover to left
and then lift up the bulb holder.
5. Replace the bulb with a 30 watt appliance bulb.
6.
Replace the bulb holder and screw.
7. Slide in vent grille and replace the mounting screw.
Replace the mounting screws. Turn the power
back on at the main power supply.
COOKTOP/NIGHT LIGHT
REPLACEMENT
3. Replace the halogen lamp.
4. Replace the halogen lamp cover and mounting
screws.
5. Turn the power back on at the main power supply.
2. Remove the halogen lamp cover mounting screws.
1. Unplug the oven or turn off power at the
main power supply.
6.
Slide in vent grille and replace the mounting screw.
Turn the power back on at the main power supply
and set the clock.
5. Slide a new charcoal filter into place.
4. Remove the old filter.
1
2
1
2

LG LMV2031BD Specifications

General

Style	over the range
Color	black stainless steel
Total Capacity	2 cu. ft.
Convection	no
Power Levels	10
Fan Speeds	4
Venting Type	convertible
Sensor Cooking	yes
Quick Start	yes
Control Type	smoothtouch™ glass controls
Timer	yes
Interior Light	incandescent; yes
Wi-Fi	no
Remote Control	no
Microwave Power	1, 000 watts
Voltage	120 volts
Current	15

Weight and Dimensions

Depth	15 13/16 inch
Height	16 7/16 inch
Width	29 14/16 inch
Net Weight	54.5 (approx) lbs.
