27
MAINTENANCE
CHARCOAL FILTER
REPLACEMENT
If your oven is vented inside, the charcoal filter
(5230W1A003A) should be replaced every 6 to 12 months,
and more often if necessary. The charcoal filter cannot be
cleaned. To order a new charcoal filter, contact the Parts
Department at your nearest Authorized Service Center.
1. Unplug the oven or turn off power at the main power
supply.
2. Open the door and remove the two vent grille
mounting screws. (2 middle screws)
3. Slide the grille left and tip forward, then lift out to
remove.
4. Remove old filter.
5. Slide a new charcoal filter into place. The filter
should rest at the angle shown.
6. Slide the bottom of the grille into place. Push the top
and slide right until it snaps into place. Replace the
mounting screws. Turn the power back on at the
main power supply and set the clock.
COOKTOP/NIGHT LIGHT
REPLACEMENT
1. Unplug the oven or turn off power at the main power
supply.
2. Remove the bulb cover mounting screws.
3. Replace bulb(s) with 20~40 watt appliance bulb(s).
4. Replace bulb cover, and mounting screws.
5. Turn the power back on at the main power supply.
OVEN LIGHT REPLACEMENT
1. Unplug oven or turn off power at the main power
supply.
2. Open the door and remove the two vent grille
mounting screws. (2 middle screws)
3. Slide the grille left and tip the cover forward, then lift
out to remove.
4. Lift up the bulb holder.
5. Replace bulb with a 30 or 40 watt appliance bulb.
6. Replace the bulb holder, if damaged.
7. Slide the bottom of the vent cover into place. Push
the top and slide right until it snaps into place.
Replace the mounting screws. Plug in microwave
oven or reconnect power.
To avoid risk of personal injury or property
damage, do not operate oven hood without filters
in place.
To avoid personal injury or property damage, wear
gloves when replacing light bulb.
