LG LP1414SHR User Manual

INSTALLATION INSTRUCTIONS
WINDOW VENT PANEL AND EXTENSIONS
The window installation kit allows you to install the air conditioner in most vertical-sliding windows
18" to 50" wide, or casement-style windows from 18" to 50 " high.
For an 18" window opening, use the window
vent panel by itself.
For window openings from 19" to 26",
use the window vent panel (Panel A) and a
extension panel (Panel B).
use the window vent panel (Panel A) and a
extension panel (Panel C).
For window openings from 35 " to 50", use the
window vent panel and two extension panels
(Panel C and Panel D).
Panel A
Panel A
18"
18"
Panel A
19"− 26"
19"− 26"
Panel B
Panel A
English
Fig. “a”
Fig. “b”
27"−34"
Fig. “c”
Fig. “d”
For window openings from 27 " to 34",
A B C D
18" 9" 17" 17"
18"
√
a
19" − 26"
√ √
b
√ √
c
√
d
Fig.
Panel
Window Length
17
√ √
1. Please check your window length and choose the
fit panels from the above tabel.
retfa ,slenap 2 naht erom deen htgnel wodniw ruoy fI .2
adjust the length, please use type A screw to fix them.
Panel D
Panel A
Panel C
Panel A
Panel C
Panel D
Panel A
Panel C
Screw A
27" − 34"
35" − 50"
27"−34"
35"−50"
35"−50"
Window Installation Kit (includes 1 Window
Vent Panel and 3 Extension Panels)
Panel A (18’’)
Panel C (17’’)
Panel D (17’’)
Panel B (9’’)
1 Window Vent Panel
3 Extension Panels
Panel B
Panel A
Panel C
