LG LPC-LM440A/X User Manual

- 2-4 -
READING OK CHECK (=“NO DISC ”DISPLAY)
CONNECTOR LOCKING
CHECK(PN801)
CHECK PN802 Pin3,4
(SL+,SL-)
CHECK PN801 Pin13,16
(FA-,FA+)
CHECK PN802 Pin5,6
(SP+,SP-)
CHECK PN801 Pin14,15
(TA+,TA-)
CHECK PN801 Pin10(LD)
DEFECTIVE PICKUP OR
IC802 OR IC801
DEFECTIVE PICKUP OR
IC802 OR IC801
DEFECTIVE PICK-UP OR
IC802 OR IC801
DEFECTIVE PICKUP OR
IC802 OR IC801
DEFECTIVE PICKUP OR
IC801 OR Q801
DOES SLED MOVE?
DOSE LENSE MOVE?
(UP&DOWN)
DOSE LASER LIGHT?
DOES SPINDLE ROTATE?
IS READING OK?
YES
YES
YES
NO
NO
NO
NO
NO
NO
NO
NO
NO
NO
YES
YES
A
B
C
D
E
