Care and Maintenance
How to Dismantle Parts
Freezer
Compartment
Lamp
Dispenser Lamp
Freezer
Compartment
Shelf
Door Rack and
Support
Ice Storage Bin
After Dispenser
Is Used
Seperate the lamp by pulling it out, and then
remove the lamp. Max. 15 W bulb for
refrigerator is used and can be purchased at a
service center.
To remove a shelf, lift the left part of the shelf
a bit, push it to the direction , lift the right part
to the direction , and take it out.
Lift the door rack holding both sides and
pull it out to direction.
Lift the ice shelf as shown in the right figure
and pull it out .
The water collector has no self-draining
function. It should be cleaned regularly.
Remove the cover by pulling the front side of
water collector cover and dry it with a cloth.
Hold the ice storage bin as shown in the right
figure and pull it out ➃ while slightly lifting it ➂.
•
Dismantling is done in the reverse sequence of assembly.
Be sure to unplug the power plug before dismantling and assembly.
Never apply severe force to dismantle parts. Parts may be damaged.
NOTE
Separate the lamp by pulling it out ➂
while
slightly striking
➀ and rotating ➁
the lamp cover.
Turn the bulb counterclockwise. Max. 40 W
bulb
for refrigerator is used and can be purchased at
a service center.
Care and Maintenance
It is recommended not to dismantle the ice
storage bin unless it is necessary.
Use both hands to remove the ice bin to avoid
dropping it.
If the ice bin does not slide into place easily,
twist the drive device slightly.
