3-10
Copyright © LG Electronics Inc. All rights reserved.
Only training and service purposes
COMPONENT ACCESS
REMOVING THE BROIL BURNER ASSEMBLY
1. Turn off the electrical supply and gas supply going
to the range.
2. Remove the oven door and remove the racks
from inside the oven.
3. To remove the broil Burner assembly:
a) Remove the back cover (see "Removing the
Back Cover" Page 3-2).
b) Remove the igniter connector from the behind.
c) Remove the wire cover by removing the screw.
d) Remove the 5 screws in the order for easily
removing.
d-1
d-4
d-2
d-3
c-1
d-5
NOTE
: When removing the screws, make sure
holding the Broil burner assembly.
4. To remove the igniter:
a) Perform step 1-3 on this page.
b) Remove the 2 screws and then remove the
igniter.
2 screws
WARNING
• DISCONNECT power supply cord
from the outlet before servicing.
• Replace all panels and parts before
operating.
•
RECONNECT all grounding devices.
- Failure to do so can result in severe personal
injury, death or electrical shock.
• Make sure the igniter connecter is
completely outside when reinstalling
the broil burner assembly.
CAUTION
• Be careful when you work on the
gas range handling the sheet metal
part.
- Sharp edge may be present and you can cut
yourself.

LG LSGL6337F Specifications

General

Style	slide-in
Color	stainless steel
Main Capacity	6.3 cu. ft.
Options	smoothtouch™ glass
Cooking Programs	bake, broil, convection bake, convection roast, multi-rack convection baking, delay bake, delay clean, proof, warm, pizza
Temperature Probe	yes
Convection	yes
Grill	no
Induction	no
Number of Burners	5
Number of Racks	3
Control Type	front tilt-control knobs; glass touch (smoothtouch™); knobs; touch sensor
Interior Light	yes
Remote Control	yes
Smart Home	thinq®, google assistant, amazon alexa, sidechef, innit, drop, tovala
Wi-Fi	yes
Fuel	natural gas; gas
Voltage	120 volts
Frequency	60 hz
Current	15a

Weight and Dimensions

Depth	28 15/16 inch
Height	37 7/8 inch
Width	30 inch; 29 7/8 inch; 29 7/8"
