SPECIFICATIONS
General
Power supply Refer to main label.
Power consumption Refer to main label.
Net Weight 4.7 kg
External dimensions (W x H x D) 270 x 295 x 320 mm
Operating temperature 5
°C to 35°C
Operating humidity 5% to 85 %
Tuner
FM Tuning Range 87.5 - 108.0 MHz or 65.0 - 74.0 MHz, 87.5 - 108.0 MHz
Intermediate Frequency 10.7 MHz
AM Tuning Range 522 - 1,620 kHz or 520 - 1,720 kHz
Amplifier
Output Power 12.5 W + 12.5 W
T.H.D 10 %
Frequency Response 40 - 20000 Hz
Signal-to-noise ratio 75 dB
CD player
Frequency response 40 - 18000Hz
Signal-to-noise ratio 75 dB
Dynamic range 75 dB
Speakers (MCS23F)
Type Bass Reflex 1 Way 1 Speaker
Impedance 4 Ω
Frequency Response 70 - 20000 Hz
Sound Pressure Level 82 dB/W (1m)
Rated Input Power 12.5 W
Max. Input Power 25 W
Net Dimensions (WxHxD) 178 x 298 x 196 mm
Net Weight (1EA) 1.9 kg
