1. Multiple piping type MULTI F
4 _ Heat Pump 50Hz/R410A
Part 2 Product data_Outdoor units
1.3 Specifications
Note :
1. All data are based on the following conditions:
- Cooling Temperature : Indoor 27°C(80.6°F) DB / 19°C(66.2°F) WB
Outdoor 35°C(95°F) DB / 24°C(75.2°F) WB
- Heating Temperature : Indoor 20°C(68°F) DB / 15°C(59°F) WB
Outdoor 7°C(44.6°F) DB / 6°C(42.8°F) WB
- Piping Length : Interconnected Pipe Length = 7.5m
- Difference Limit of Elevation (Outdoor ~ Indoor Unit) is Zero.
2. Wiring cable size must comply with the applicable local and national code.
3. Due to our policy of innovation some specifications may be changed without notification.
4. Sound Level Values are measured at Anechoic chamber.
Therefore, these values can be increased owing to ambient conditions during operation.
Outdoor unit
A2UW14GFA0
[MU2M15 UL2]
A2UW16GFA0
[MU2M17 UL2]
Testing Combination
Capacity
Cooling
Min.~Rated~Max. kW
Min.~Rated~Max. Btu/h
Heating
Min.~Rated~Max. kW
Min.~Rated~Max. Btu/h
Power Input
Cooling Min.~Rated~Max. kW
Heating Min.~Rated~Max. kW
SEER / SCOP Wh / Wh
Seasonal Energy Label Cooling / Heating -
Annual Energy Consumption Cooling / Heating kWh
Power Supply V , Ø , Hz
Running Current
Cooling Min.~Rated~Max. A
Heating Min.~Rated~Max. A
Starting Current
Cooling Max. A
Heating Max. A
Wiring Connections
Power Supply Cable (included Earth) No. x mm
2
(AWG)
Power and Communication Cable (included Earth) Outdoor ~ BD unit No. x mm
2
(AWG)
Combination
Sum of Indoor Units Capacity kBtu/h
Number of Indoor Units EA
Number of BD Units EA
Casing Color -
Dimensions
W x H x D mm
W x H x D inch
Net Weight kg (lbs)
Compressor
Type -
Model Model x No.
Motor type -
Motor Output W x No.
Refrigerant
Type -
Precharged Amount g (oz)
Chargeless-Pipe Length m (ft)
Additional Charging Volume g/m (oz/ft)
Control -
Refrigerant Oil
Type -
Charged volume cc x No.
Heat Exchanger (Row x Column x Fins per inch) x No. -
Fan
Type -
Air Flow Rate m
3
/min x No.
Fan Motor
Type
Output W x No.
Sound Pressure Level
Cooling Rated dB(A)
Heating Rated dB(A)
Sound Power Level Cooling Max. dB(A)
Piping Connections
Liquid Outer Dia. mm(inch) x No.
Gas Outer Dia. mm(inch) x No.
Piping Length
Total Piping Max. m (ft)
Main Piping Max. m (ft)
Total Branch Piping Max. m (ft)
Each Branch Piping Max. m (ft)
Maximum Height
Difference
Outdoor Unit ~ Indoor Unit Max. m (ft)
Indoor Unit ~ Indoor Unit Max. m (ft)
Operation Range
(Outdoor Temperature)
Cooling Min. ~ Max. ℃ DB (℉ DB)
Heating Min. ~ Max. ℃ WB (℉ WB)
MS07AQ NB0 x 2EA MS09AQ NB0 x 2EA
0.88 ~ 4.10 ~ 5.39 0.88 ~ 4.69 ~ 5.39
3,000 ~ 14,000 ~ 18,400 3,000 ~ 16,000 ~ 18,400
0.97 ~ 4.69 ~ 5.69 0.97 ~ 5.27 ~ 5.69
3,300 ~ 16,000 ~ 19,400 3,300 ~ 18,000 ~ 19,400
0.29 ~ 1.02 ~ 1.63 0.29 ~ 1.26 ~ 1.63
0.29 ~ 1.08 ~ 1.66 0.29 ~ 1.28 ~ 1.66
6.1 / 3.8 6.1 / 3.8
A++ / A A++ / A
235 / 1,732 270 / 1,842
220-240, 1, 50 220-240, 1, 50
1.3 ~ 4.6 ~ 7.4 1.3 ~ 5.8 ~ 7.4
1.3 ~ 4.9 ~ 7.5 1.3 ~ 5.8 ~ 7.5
--
--
3C x 2.5 (12) 3C x 2.5 (12)
--
21 24
22
--
Warm Gray Warm Gray
770 × 545 × 288 770 × 545 × 288
30-5/16 x 21-15/32 x 11-11/32 30-5/16 x 21-15/32 x 11-11/32
37 (81.6) 37 (81.6)
Twin Rotary Twin Rotary
GKT141MA x 1 GKT141MA x 1
BLDC BLDC
1,500 (at 60Hz) x 1 1,500 (at 60Hz) x 1
R410A R410A
1,400 (49.4) 1,400 (49.4)
15 (49.2) 15 (49.2)
20 (0.22) 20 (0.22)
Electronic Expansion Valve Electronic Expansion Valve
FVC68D FVC68D
570 x 1 570 x 1
(2 x 24 x 14) x 1 (2 x 24 x 14) x 1
Propeller Propeller
28.2 x 1 28.2 x 1
BLDC BLDC
43 x 1 43 x 1
49 49
51 51
59 62
Ø 6.35 (1/4) x 2 Ø 6.35 (1/4) x 2
Ø 9.52 (3/8) x 2 Ø 9.52 (3/8) x 2
30 (98.4) 30 (98.4)
--
--
20 (65.6) 20 (65.6)
15 (49.2) 15 (49.2)
7.5 (24.6) 7.5 (24.6)
-10 (14.0) ~ 46 (114.8) -10 (14.0) ~ 46 (114.8)
-18 (-0.4) ~ 18 (64.4) -18 (-0.4) ~ 18 (64.4)
