28 _ Heat Pump 60Hz/R410A
Part 2 Product data_Outdoor units
Models : A2UW16GFA0
[Cooling capacity]
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
Combination
capacity index
(kBtu/h)
Outdoor
air temp.:
(°CDB)
Operation
14 16 18 19 22 24
Indoor air temp.: (°CWB)
1 Unit
2 Units
22 6.66 0.28 7.07 0.38 7.49 0.41 7.70 0.42 8.32 0.42 8.74 0.42
25 6.50 0.30 6.92 0.39 7.33 0.42 7.54 0.43 8.17 0.44 8.58 0.44
32 6.13 0.40 6.55 0.48 6.97 0.50 7.17 0.50 7.80 0.52 8.22 0.53
35 5.98 0.45 6.39 0.51 6.81 0.53 7.00 0.52 7.64 0.55 8.06 0.56
40 5.71 0.49 6.13 0.53 6.55 0.54 6.76 0.54 7.38 0.55 7.80 0.56
43 5.56 0.48 5.97 0.51 6.39 0.51 6.60 0.50 7.22 0.51 7.64 0.52
46 5.40 0.43 5.82 0.44 6.23 0.43 6.44 0.42 7.07 0.43 7.48 0.44
22 8.56 0.36 9.09 0.48 9.63 0.52 9.90 0.53 10.70 0.54 11.24 0.54
25 8.36 0.38 8.89 0.50 9.43 0.54 9.70 0.55 10.50 0.55 11.03 0.56
32 7.89 0.51 8.42 0.60 8.96 0.63 9.22 0.64 10.03 0.66 10.56 0.67
35 7.68 0.57 8.22 0.65 8.75 0.67 9.00 0.66 9.83 0.69 10.36 0.71
40 7.35 0.63 7.88 0.68 8.42 0.68 8.69 0.69 9.49 0.70 10.02 0.71
43 7.14 0.61 7.68 0.64 8.22 0.64 8.48 0.64 9.29 0.65 9.82 0.66
46 6.94 0.55 7.48 0.56 8.01 0.54 8.28 0.54 9.08 0.54 9.62 0.55
22 11.41 0.48 12.13 0.65 12.84 0.70 13.20 0.71 14.27 0.71 14.98 0.71
25 11.14 0.51 11.86 0.66 12.57 0.72 12.93 0.73 14.00 0.74 14.71 0.75
32 10.51 0.68 11.23 0.80 11.94 0.84 12.30 0.85 13.37 0.87 14.08 0.89
35 10.25 0.76 10.96 0.86 11.67 0.90 12.00 0.88 13.10 0.92 13.81 0.94
40 9.80 0.84 10.51 0.90 11.22 0.91 11.58 0.92 12.65 0.93 13.36 0.95
43 9.53 0.82 10.24 0.86 10.95 0.86 11.31 0.85 12.38 0.86 13.10 0.88
46 9.26 0.73 9.97 0.74 10.68 0.73 11.04 0.72 12.11 0.72 12.83 0.74
22 13.31 0.55 14.15 0.75 14.98 0.81 15.40 0.82 16.65 0.83 17.48 0.83
25 13.00 0.59 13.83 0.77 14.67 0.83 15.08 0.84 16.33 0.86 17.16 0.86
32 12.27 0.79 13.10 0.93 13.93 0.98 14.35 0.99 15.60 1.01 16.43 1.03
35 11.95 0.88 12.79 1.00 13.62 1.04 14.00 1.02 15.28 1.07 16.12 1.09
40 11.43 0.97 12.26 1.04 13.09 1.06 13.51 1.06 14.76 1.08 15.59 1.10
43 11.11 0.95 11.95 0.99 12.78 0.99 13.20 0.99 14.45 1.00 15.28 1.02
46 10.80 0.85 11.63 0.86 12.47 0.84 12.88 0.83 14.13 0.83 14.96 0.85
22 15.22 0.68 16.17 0.92 17.12 1.00 17.60 1.01 19.02 1.02 19.98 1.02
25 14.86 0.73 15.81 0.95 16.76 1.03 17.24 1.04 18.66 1.06 19.62 1.07
32 14.02 0.98 14.97 1.15 15.92 1.21 16.40 1.22 17.83 1.25 18.78 1.27
35 13.66 1.09 14.61 1.24 15.56 1.28 16.00 1.26 17.47 1.32 18.42 1.35
40 13.06 1.20 14.01 1.29 14.96 1.31 15.44 1.31 16.87 1.33 17.82 1.36
43 12.70 1.17 13.65 1.23 14.61 1.22 15.08 1.22 16.51 1.23 17.46 1.26
46 12.34 1.05 13.29 1.06 14.25 1.04 14.72 1.03 16.15 1.03 17.10 1.05
22 18.07 0.68 19.20 0.92 20.33 1.00 20.90 1.01 22.59 1.02 23.72 1.02
25 17.64 0.73 18.77 0.95 19.90 1.03 20.47 1.04 22.16 1.06 23.29 1.07
32 16.65 0.98 17.78 1.15 18.91 1.21 19.47 1.22 21.17 1.25 22.30 1.27
35 16.22 1.09 17.35 1.24 18.48 1.28 19.00 1.26 20.74 1.32 21.87 1.35
40 15.51 1.20 16.64 1.29 17.77 1.31 18.34 1.31 20.03 1.33 21.16 1.36
43 15.08 1.17 16.21 1.23 17.34 1.22 17.91 1.22 19.60 1.23 20.73 1.26
46 14.66 1.05 15.79 1.06 16.92 1.04 17.48 1.03 19.18 1.03 20.31 1.05
22 17.12 0.68 18.19 0.92 19.26 1.00 19.80 1.01 21.40 1.02 22.47 1.02
25 16.71 0.73 17.79 0.95 18.86 1.03 19.39 1.04 21.00 1.06 22.07 1.07
32 15.77 0.98 16.84 1.15 17.91 1.21 18.45 1.22 20.05 1.25 21.12 1.27
35 15.37 1.09 16.44 1.24 17.51 1.28 18.00 1.26 19.65 1.32 20.72 1.35
40 14.69 1.20 15.76 1.29 16.84 1.31 17.37 1.31 18.98 1.33 20.05 1.36
43 14.29 1.17 15.36 1.23 16.43 1.22 16.97 1.22 18.57 1.23 19.64 1.26
46 13.89 1.05 14.96 1.06 16.03 1.04 16.56 1.03 18.17 1.03 19.24 1.05
22 19.97 0.68 21.22 0.92 22.47 1.00 23.09 1.01 24.97 1.02 26.22 1.02
25 19.50 0.73 20.75 0.95 22.00 1.03 22.62 1.04
24.50 1.06 25.75 1.07
32 18.40 0.98 19.65 1.15 20.90 1.21 21.52 1.22 23.40 1.25 24.65 1.27
35 17.93 1.09 19.18 1.24 20.43 1.28 21.00 1.26 22.93 1.32 24.17 1.35
40 17.14 1.20 18.39 1.29 19.64 1.31 20.27 1.31 22.14 1.33 23.39 1.36
43 16.67 1.17 17.92 1.23 19.17 1.22 19.79 1.22 21.67 1.23 22.92 1.26
46 16.20 1.05 17.45 1.06 18.70 1.04 19.32 1.03 21.20 1.03 22.45 1.05
22 22.83 0.68 24.25 0.92 25.68 1.00 26.39 1.01 28.54 1.02 29.96 1.02
25 22.29 0.73 23.71 0.95 25.14 1.03 25.86 1.04 28.00 1.06 29.42 1.07
32 21.03 0.98 22.46 1.15 23.88 1.21 24.60 1.22 26.74 1.25 28.17 1.27
35 20.49 1.09 21.92 1.24 23.35 1.28 24.00 1.26 26.20 1.32 27.63 1.35
40 19.59 1.20 21.02 1.29 22.45 1.31 23.16 1.31 25.30 1.33 26.73 1.36
43 19.05 1.17 20.48 1.23 21.91 1.22 22.62 1.22 24.76 1.23 26.19 1.26
46 18.51 1.05 19.94 1.06 21.37 1.04 22.08 1.03 24.22 1.03 25.65 1.05
7
9
12
7 + 7
7 + 9
7 + 12
9 + 9
9 + 12
12 + 12
1.8 Capacity tables
Notes:
1. Capacities are based on the following conditions.
Corresponding refrigerant piping length : 7.5m
Level difference : 0m
2. TC : Total Capacity (kW)
PI : Power Input (kW)
