Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
MA
TI
F
TI
Table 5: Multi F Multi Zone Ceiling Cassette Indoor Unit Specications.
GENERAL DATA
Specications
Model Name LMCN077HV LCN097HV4 LCN127HV4 LMCN185HV
Grille (Sold Separately)
PT-QCHW0 /
PT-UQC
PT-QCHW0 /
PT-UQC
PT-QCHW0 /
PT-UQC
PT-QCHW0 /
PT-UQC
Nominal Cooling Capacity (Btu/h)
1
7,000 9,000 12,000 18,000
Nominal Heating Capacity (Btu/h)
1
8,100 10,400 13,800 20,800
Operating Range
Cooling (°F WB) 57-77
Heating (°F DB) 59-81
Fan
Type Turbo
Motor Output (W) x Qty. 43 x 1
Motor/Drive Brushless Digitally Controlled / Direct
Airflow Rate CFM (H/M/L) 265 / 212 / 177 300 / 265 / 230 335 / 283 / 247 459 / 424 / 388
Unit Data
Refrigerant Type
2
R410A
Refrigerant Control EEV
Power Supply V, Ø, Hz
3
208-230, 1, 60
Rated Amps (A) 0.25
Sound Pressure Level ±3 dB(A) (H/M/L)
4
31 / 27 / 24 36 / 33 / 30 38 / 35 / 32 38 / 37 / 34
Body Dimensions (W x H x D, in.) 22-7/16 x 8-7/16 x 22-7/16 22-7/16 x 10-3/32 x 22-7/16
Grille (PT-UQC, sold separately) Dimensions (WxHxD, in.) 27-9/16 x 7/8 x 27-9/16
Body Net Weight (lbs.) 31 34
Grille (Sold separately) Net Weight (lbs.) 7
Body Shipping Weight (lbs.) 34 37 42
Grille (Sold separately) Shipping Weight (lbs.) 11 9 9 11
Power Wiring / Communications Cable (No. x AWG)
5
4 x 18
Heat Exchanger (Row x Column x Fin / inch) x No. (2 x 8 x 18) x 1 (2 x 10 x 18) x 1
Pipe Size
Liquid (in.) 1/4
Vapor (in.) 3/8 1/2
Drain O.D. / I.D. (in.) 1-1/4, 1
1
Nominal capacity is rated 0 ft. above sea level with corresponding refrigerant piping
length in accordance with standard length of each outdoor unit and a 0 ft. level difference
between outdoor and indoor units. All capacities are net with a combination ratio between
95 – 105%.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb
(DB) and 67ºF wet bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and
75ºF wet bulb (WB).
Nominal heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb
(DB) and 60ºF wet bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and
43ºF wet bulb (WB).
2
This unit comes with a dry helium charge.
3
Acceptable operating voltage: 187V-253V.
4
Sound pressure levels are tested in an anechoic chamber under ISO Standard 3745 and
are the same in both cooling and heating mode. These values can increase due to ambient
conditions during operation.
5
All power wiring / communications cable to the IDUs be minimum 18 AWG, 4-conductor,
stranded, shielded or unshielded (if shielded, must be grounded to chassis at ODU only)
and must comply with applicable local and national codes.
