5 Appendix
Appendix 43
Appendix
5
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption Refer to the main label on the unit.
Dimensions (W x H x D)
Approx. 330.0 mm x 716.0 mm x 318.0 mm
(13.0 inch x 28.2 inch x 12.5 inch)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 60 %
Inputs
Analog audio in (AUX IN) 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
Portable in (PORT. IN) 1.0 Vrms (3.5 mm stereo jack) x 1
Microphone (MIC 1/2) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 2
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 40 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 80 dB
Bus Power Supply (USB)
5 V 0 500 mA
Amplier (RMS Output power)
Total output 500 W RMS
HIGH 165 W RMS × 2 (8 Ω at 1kHz, 10% THD)
LOW 170 W RMS (3 Ω at 200Hz, 10% THD)
y Design and specications are subject to change without notice.
