52
206-4232
FTG File Manager Utilities Overview (Cont.)
DELETE
Click to remove highlighted
channel from FTG Channel
Map.
ADD
After defining a new
Logical Channel, click to
add channel to the FTG
Channel Map.
FTG Channel Map Editor
The FTG Channel Map Editor shows a single Logical Channel’s data and the FTG Channel Map.
EXIT
Click to exit editor and
return to FTG Channel
Map Configuration Utility.
LOGICAL CHANNEL MAPPING
Select a Logical Channel number. Then,
assign the RF, Major, and Minor channel
numbers to complete the mapping.
CUSTOM CHANNEL LABELS/ICONS
Enter custom labels and select icons
by name on menu or by number.
SET CHANNEL ATTRIBUTES
Check/select Encrypted, OSD,
or Blank Video.
UPDATE
After editing an existing
Logical Channel’s data,
click to commit the changes
in the FTG Channel Map.
ZONE RESTRICTION
Select Zone restriction
for channel. See
Reference section,
“Using the TV Zoning
Feature,” for further
information.
To Next Page
