CONTROL LAY-OUT
8
16
MODEL
PWB ASSEMBLY DISPLAY LAY-OUT
PWB ASSEMBLY LAY-OUT
P/NO
EBR50559201
OPTION PART
RC8011*
RC9011*
DP1
X
DP2
X
DP3
X
DP4
X
DP5
X
DP6
X
EBR50559202
RC8011**
RC9011**
O : Option diode(DP) applied
X : Option diode(DP) not-applied
XXOXXX
