Appendix 53
Appendix
5
Specifications
General
Power requirements Refer to the main label on the unit.
Power consumption Refer to the main label on the unit.
Dimensions (W x H x D)
Approx. 1443.0 mm x 63.0 mm x 146.0 mm (with foot)
(56.8 inch x 2.5 inch x 5.7 inch)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Bus Power Supply (USB) 5 V
0
500 mA
Available Digital Input Audio
Sampling Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 192 kHz
Available Digital Input Audio format Dolby Atmos, Dolby Audio, DTS:X, DTS-HD, PCM
Input/Output
OPTICAL IN 3 V (p-p), Optical jack x 1
HDMI IN (1) / HDMI IN (2) 19 Pin (Type A, HDMI™ connector) x 2
HDMI OUT
19 Pin (Type A, HDMI™ connector) x 1
4K Sources dependent on HDCP 2.3 are supported at 4K resolutions.
Amplier (RMS Output)
Total 570 W RMS
Front 50 W RMS x 2 (4
Ω
at 1 kHz, THD 10 %)
Center 50 W RMS (4
Ω
at 1 kHz, THD 10 %)
Surround 50 W RMS x 2 (4
Ω
at 1 kHz, THD 10 %)
Top 50 W RMS x 2 (4
Ω
at 1 kHz, THD 10 %)
Subwoofer 220 W RMS (3
Ω
at 80 Hz, THD 10 %)

LG SN10YG Specifications

General

Audio decoders	DTS Digital Surround, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
RMS rated power	570 W
Audio output channels	5.1.2 channels
Audio Return Channel (ARC)	Yes
Soundbar speaker RMS power	250 W
Subwoofer connectivity	Wireless
Ethernet LAN	No
Bluetooth version	5.0
HDMI ports quantity	3
Digital audio optical out	1
FM radio	-
Product color	Silver
Virtual assistant	Google Assistant
Audio formats supported	AAC, AAC+, FLAC, MP3, OGG, WAV
Consumer Electronics Control (CEC)	SimpLink
Package depth	284 mm
Package width	1516 mm
Package height	472 mm
Package weight	19300 g

Weight and Dimensions

Depth	1443 mm
Width	146 mm
Height	63 mm
Soundbar weight	7500 g
Subwoofer depth	221 mm
Subwoofer width	312.8 mm
Subwoofer height	390 mm
Subwoofer weight	7800 g
