LG WT1001CW User Manual

10
INSTALLATION INSTRUCTIONS
CONNECTING THE WATER LINES
y LG recommends the use of LG hoses. Any leak-
ing, property damage, or damage to the washing
machine caused by an improper installation or by
the use of Non-LG hoses is not covered under the
terms of the LG warranty and is the sole responsi-
bility of the customer and/or an installer.
y Water supply pressure must be between 14.5 psi
and 116 psi (100~800 kPa). If the water supply pressure
is more than 116 psi, a pressure reducing valve must
be installed.
y Periodically check the hose for cracks, leaks, and
wear, and replace the hose if necessary.
y Make sure that the water lines are not stretched,
pinched, crushed, or kinked.
y The washer should never be installed or stored in a
location subject to freezing temperatures. Damage to
the water lines and internal mechanisms of the washer
can result. If the washer was exposed to freezing tem-
peratures prior to installation, allow it to stand at room
temperature for several hours before use and check for
leaks prior to operation.
1. Inspect the threaded fitting on each hose and
make sure there is a rubber seal in place in both
ends.
2. Connect the water supply hoses to the HOT and
COLD water faucets tightly by hand and then tight-
en another 2/3 turn with pliers.
Water Faucet
3. Always run a gallon or two of water through each
inlet hose to flush dirt, scale and other debris out
of the water lines. Doing so will help prevent future
problems with clogged filter screens, and will also
allow you to verify which hose is hot and which
is cold.
4. Attach the hot water line to the hot water inlet on
the back of the washer. Attach the cold water line
to the cold water inlet on the back of the washer.
Tighten the fittings securely. Turn ON both fau-
cets all the way and check for leaks at both ends
of the hoses.
NOTE: Be careful not to cross-thread the hose fit-
tings. This will damage the valve and could result in
property damage from leaks.
Rubber Seal
Water Hose
(to tap)
Water Hose
(to water inlet
on washer)
Rubber Seal
y
Do not reuse old hoses.
Only use new hoses
when you install the washing machine. Old
hoses could leak or burst causing flooding and
property damage.
y
Do not overtighten the hoses.
Overtightening
can damage the valves resulting in leaking and
property damage.
y
Do not overtighten.
Damage to the coupling
can result.
Cold water inlet
Hot water inlet
WARNING
WARNING
WARNING

LG WT1001CW Specifications

General

Door hinge	Up
Motor type	Beltless
Control type	Buttons
Display type	LED
Loading type	Top-load
Tub material	Plastic
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	- kg
Delay start (max)	19 h
Spin-drying class	-
Maximum spin speed	1100 RPM
Noise level (wash)	- dB
Number of washing programs	8
Current	10 A
AC input voltage	120 V
Energy consumption washing per cycle	- kWh
Sustainability certificates	ENERGY STAR
Package depth	787 mm
Package width	736 mm
Package height	1092 mm
Package weight	58967 g

Weight and Dimensions

Depth	660 mm
Width	635 mm
Height	1016 mm
Weight	49985.8 g
