LG WT1001CW User Manual

9
ENGLISH
INSTALLATION INSTRUCTIONS
UNPACKING AND REMOVING SHIP-
PING MATERIAL
1. After removing the carton and shipping material,
lift the washer off the foam base. Make sure the
plastic tub support comes off with the base and is
not stuck to the bottom of the washer.
If you must lay the washer down to remove the base
packaging materials, always protect the side of the
washer and lay it carefully on its side. DO NOT lay
the washer on its front or back.
2. Save the foam block (that contains the Own-
er’s Manual, parts and laundry product sam-
ples) for future use. If the washer must be
moved in the future, this will help prevent
damage to the washer during transportation.
NOTE: To prevent damage, do not remove the
foam block until the washer is at the final location.
3. Unfasten the power cord from the back of the
washer.
TOOLS YOU WILL NEED
y Adjustable Pliers
y Carpenter's Level
Plastic Tub Support
Carton Base

LG WT1001CW Specifications

General

Door hinge	Up
Motor type	Beltless
Control type	Buttons
Display type	LED
Loading type	Top-load
Tub material	Plastic
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	- kg
Delay start (max)	19 h
Spin-drying class	-
Maximum spin speed	1100 RPM
Noise level (wash)	- dB
Number of washing programs	8
Current	10 A
AC input voltage	120 V
Energy consumption washing per cycle	- kWh
Sustainability certificates	ENERGY STAR
Package depth	787 mm
Package width	736 mm
Package height	1092 mm
Package weight	58967 g

Weight and Dimensions

Depth	660 mm
Width	635 mm
Height	1016 mm
Weight	49985.8 g
