LG WT1201CV User Manual

16
INSTALLATION INSTRUCTIONS
Raise
front to back
side to side
Lower
If the washer is not level, adjust the leveling feet. Turn
clockwise to raise, counterclockwise to lower.
4
Check the washing machine’s level again.
- Push or rock the top edges of the washing machine
gently to make sure that the washing machine does not
rock.
- If the washing machine rocks, repeat steps 1 to 3.
WARNING
Using the washing machine without leveling, may
y
result in malfunction caused by the production of
excess vibration and noise.
Only use the leveling feet to level the machine.
y
If you
raise the leveling feet unnecessarily, it may cause
abnormal vibration of the washing machine.
Leveling the Washing machine
The washer spins at very high speeds, up to 1,100 RPM.
NOTE
Adjust the leveling feet only as far as necessary to
y
level the washer. Extending the leveling feet more than
necessary can cause the washer to vibrate.
All four leveling feet must rest solidly on the floor. Rock
y
the washer gently from corner to corner to make sure
that the washer does not rock.
Before installing the washer, make sure the floor is
y
clean, dry and free of dust, dirt, water and oils so the
washer feet cannot slide easily. Leveling feet that can
move or side on the floor can contribute to excess
vibration and noise due to poor contact with the floor.
1
Position the washer in the final location,
taking special care to not pinch, strain, or crush the water
and drain lines. Place a level across the top of the washer.
2
Adjust the leveling feet. Turn clockwise to raise the
washer or counterclockwise to lower it.
Raise Lower
3
To make sure that the washer is properly level, open
the lid and look from above to see if it is same as shown
below. If you have a level, check your washer with the
level.
• To check if the washer is level side to side, close the lid
and place a level at the back of the lid.
• To check if the washer is level front to back, place a level at
the side of the washer on the edge where the cabinet side
meets the top cover.

LG WT1201CV Specifications

General

Door hinge	Up
Motor type	Beltless
Display type	LED
Loading type	Top-load
Product color	Stainless steel
Built-in display	Yes
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	- kg
Delay start (max)	19 h
Spin-drying class	-
Maximum spin speed	1100 RPM
Noise level (wash)	- dB
Number of washing programs	8
Current	5 A
AC input voltage	120 V
Water consumption per cycle	- L
Energy consumption washing per cycle	- kWh
Sustainability certificates	ENERGY STAR
Package depth	796 mm
Package width	749 mm
Package height	1110 mm
Package weight	68855 g

Weight and Dimensions

Depth	721 mm
Width	685.8 mm
Height	1020 mm
Weight	60872 g
