LifeSpan Echo User Manual

24
ECHO
10. PARTS LIST
No.
Item
Spec.
Qty.
No.
Item
Spec.
Qty.
1
Main Frame
1
43
Rubber Pad 2
2
2
Base Frame
1
44
Magnetic Ring
1
3
Upright bracket
2
45
Brown single wire
1
4
Running board
strengthen tube
2
46
Bolt
M8*25 1
5
Motor Bracket
1
47
Lock Nut
M6
6
6
Computer bracket
1
48
Screw
ST4.2*45
2
7
Rubber pad
8
49
Bolt
M6*55
1
8
Rotating pipe
2
50
Bolt
M6*65
2
9
Front Roller
1
51
Bolt
M8*16
10
10
Back Roller
1
52
Hand pulse with speed+/-
1
11
Cylinder
1
53
Bolt
M8*40
2
12
5#Allen Wrench
5mm
1
54
Bolt
M10*70
2
13
bolt
M5*15
2
55
Flat Washer
8
7
14
DC Motor
1
56
Screw
ST4.2*12
7
15
Running Board
1
57
Bolt
M5*8
4
16
Adjustable foot
pad
2
58
Lock Nut
M8 6
17
Circle end cap
2
59
Bolt
M8*25
1
18
Motor Up Cover
1
60
Bolt
ST4.8*25
4
19
Motor Bottom Cover
1
61
Oil bottle
1
20
Side Rail
2
62
Screw
ST4.8*19
4
21
Right Back End
Cover
1
63
Lock washer
5 2
22
Left Back End
Cover
1
64
Lock washer
8
10
23
Fixing plug
2
65
Lock Washer
6
3
24
Motor Belt
1
66
Bolt
M8*42
1
25
Power Wire Buckle
1
67
Spring washer
8
6
26
Running Belt
1
68
Bolt
M6*37
2
27
Foot pad
4
69
Bolt
M6*30
8
28
Ring wire plug B
2
70
Bolt
M8*45
4
29
Transport Wheel
2
71
Safety key
1
30
Wheel cover
2
72
EVA
420*20*7 2
31
Power Wire
1
73
Bolt
M6*22
4
32
Switch
1
74
Bolt
ST4.8*19
2
33
Foam
2
75
Screw driver
S=13
、
14
、
15
1
34
Bolt
ST4.2*13
3
76
Bolt
ST4.2*19
4
35
Computer cover
1
77
Left base cover
1
36
Computer seal
cover
1
78
Right base cover
1
37
Bolt
ST4.2*20
4
79
Decoration strip
1
38
Computer
1
80
Decoration sheet
1
39
Hand pulse with
start/stop
1
81
Bolt
ST2.9*9.5 4
40
Control board
1
82
Elastic cushion
2
41
Computer Bottom
Wire
1
83
Non-slip pad
2
42
Computer Up Wire
1
