Ice cubes are
sticking together
The ice cycle is too long
Stop the ice maker, and restart
it after the ice blocks melt.
Select the small ice button
Water temperature in
inner tank is too low
Change the water in the inner
tank. Temperature of water
should be between 8˚C & 32˚C
PROBLEM PROBABLE CAUSE SOLUTION
The ice making
cycle is normal
but no ice is
being produced
Ambient temperature or
water temperature in
the inner tank is too high
Refrigerant liquid
leakage
Pipe in the cooling
system is blocked
Ambient temperature
surrounding the unit is above
32 °C, move to a cooler area
and replace water in the
tank with cooler water
Please contact the service
agent
Please contact the service
agent
“Water” indicator
light is on
Lack of water in the
reservoir
Stop the icemaker, fill with
water and then restart the
ice maker
“Ice” indicator is on
There is too much ice in
the ice basket
Remove ice from the ice
basket
The “Water” & “Ice”
indicator lights are
flashing
The ice shovel cannot
move
Check the ice shovel to ensure
there is no obstruction,
otherwise consult a qualified
technician
7. Troubleshooting
Warranty Terms : 12 Months
Packed for Game (Masstores (Pty) Ltd
214 West Street, Durban, 4001
8
7
8. Parts Diagram
1. Inner Tank
2. Ice Bucket
3. Evaporator Assembly
4. Bottom Base
5. Condensor
6. DC12V / Fan Blade
7. Rear Protection Board
8. Electrical Box
9. Rear Strengthening Board
10. Rubber Feet with bolts
11. Main Control PWB
12. Transformer
13. Power Cord Clip
14. Sychronous Motor
15. Back Down Cover
16. Inner Tank Fixing Piece
17. Micro Switch
18. Ice Shovel
19. Electromagnet Valve Assembly
20. Refrigerant Dry Filter
21. Front Panel
22. Water Draining Assembly
23. Rear Panel
24. Support for Sensor
25. Ice Basket
26. Back Up Cover
27. Front Up Cover
28. Front Down Cover
29. Down Window
30. Up Window
31. Compressor
32. Steel Grill
33. Operation Panel Frame
34. Water Filter
35. Water Detecting Piece
36. Up Sponge for Compressor
37. Down Sponge for Condensor
38. Fixing set for water pump
39. DC12V / Water Pump
40. Power Supply cords
41. Button PWB
42. Silicon pipe for suppyling water
43. Silicon pipe for ice bucket
