Logitech G815 User Manual

Three onboard profiles can be saved to G915. The profiles are downloaded into the G915 through G HUB software,
and are accessed by selecting M1, M2, or M3 when the keyboard is in Onboard mode (selected from G HUB
software, or when G HUB software is off or not installed.
MEDIA CONTROLS
G815 has media controls, located in the upper tight corner of the keyboard.
Volume roller – controls volume of the active audio on your PC.
Skip Back – goes to the beginning of a track, or to a previous track, depending on the application.
Play/Pause – starts or stops the audio or video source playback.
Skip forward – goes to the end of the track or to the next track, depressing on the application.
Mute – stops audio output.
USB PASS-THROUGH
G815 has a USB port located next to the cable that can be used to connect other USB
devices more conveniently
File Downloads
User Manual
logitech, G815, Gaming Keyboard
Download [optimized]
Download
References

Logitech G815 Specifications

General

Numeric keypad	Yes
Actuation force	50 g
Keyboard layout	QWERTZ
Pointing device	No
Device interface	USB
Keyboard language	German
Recommended usage	Gaming
Key travel distance	2.7 mm
Keyboard key switch	Mechanical
Keyboard form factor	Full-size (100%)
Keyboard key switch technology	Logitech GL Linear
Product color	Carbon
Keyboard style	Straight
Cable length	1.8 m
Number of products included	1 pc(s)
Package depth	510 mm
Package width	230 mm
Package height	42 mm
Package weight	1595 g
Master (outer) case width	187 mm
Master (outer) case height	245 mm
Master (outer) case length	525 mm
Master (outer) case weight	7000 g
Harmonized System (HS) code	84716060

Weight and Dimensions

Keyboard weight	1145 g
Keyboard dimensions (WxDxH)	150 x 475 x 22 mm
