Logitech HARMONY 700 User Manual

22
Adjusting the delay between IR commands
If you find the delay between IR commands is too long, especially when changing channels on
your TV, you can change the delay time for a device that is reacting too slowly.
The Harmony 700 uses several different delays to control your devices. For more information on
which delay you need to adjust, see Types of delays or speed settings.
To adjust the input delay, from the Harmony Remote Software:
Click the 1. Devices tab.
Select the device for which you want to apply the change and click 2. Settings.
Select 3. Adjust the delays (speed settings).
Click4. Next.
Follow the online instructions.5.
To adjust the inter device delay:
Press and hold the 1. Help button on your remote for 5 seconds.
When prompted, confirm that you want to enter advanced delay mode by selecting 2. Yes.
Select the device you want to adjust the delay for.3.
Select 4. Change Delay.
Select 5. Inter Device Delay.
Adjust the inter device delay by selecting “6. +“ to increase or “-“ to decrease.
When you are finished, select 7. Done.
Repeats
The Repeats are the number of times the remote repeats a command for a device to properly
respond to the command. For instance, many devices need longer or shorter command repetitions
to respond properly.
Example: Any time I press channel up, my Digital Set Top Box skips two channels at a time.

Logitech HARMONY 700 Specifications

General

LCD Size	1.5" Diagonal
LCD Resolution	128 x 128
LCD Screen	65, 000 Color
Backlit keypad	Yes
Backlight Color	White
Power Source	Rechargeable
Power Type	NiMH AA
Brands Supported	5, 000+
Devices Supported	200, 000+
Maximum number of devices per account	6
IR Learning	Yes (Up to 200 Khz)
Learning Capabilities	Any IR Device
IR Transmitters	2
IR Transmission Range	Up to 50 ft
Warranty	2 Years
Memory Type	Flash
Memory Amount	2MB
Supported Platforms	Windows 2000/XP/Vista MAC OS X 10.3 +

Weight and Dimensions

Weight	6 oz (with battery installed)
Dimensions	8.75” x 2.3” x 1.3”
